MAINTENANCE
6-36 / Towing
© 2020 Pierce Manufacturing Inc. All Rights Reserved.
Figure 6-9: Safety Chains and Tire Straps
1254, 1255
Before transporting the disabled vehicle, ensure that safety chains and tire straps are properly installed and secure
(Figure 6-9).
6-25.8 Lift and Tow using Frame Forks
The Saber® 2014/Enforcer™ can be lifted and towed using a standard under-lift device equipped with heavy duty
frame forks. This is a third towing alternative, in addition to tire lift and flatbed transport. When applying the frame
forks to the frame extension, care must be taken to ensure that no damage to the chassis occurs. Securing the
disabled vehicle to the tow vehicle may require some disassembly and is the responsibility of the tow vehicle
operator. Pierce Manufacturing does not warranty any damage that may occur due to improper towing. The figures
below give suggested areas where the frame forks may be attached to the frame extension.
