© 2020 Pierce Manufacturing Inc. All Rights Reserved. Controls, Indicators, and Features / 4-19
GENERAL
Figure 4-8: 2014 Saber® 2014/Enforcer™ Controls and Indicators (Continued)
66-0240SH1B
4-8. Windshield Wiper System
The Saber® 2014/Enforcer™ windshield wiper control is located on the center dash near the HVAC controls. The
Saber® 2014/Enforcer™ chassis uses three wiper blades controlled by a single motor and linkage arrangement to
drive the wiper arms, providing for synchronous movement.
Item # Description Item # Description
39. Directional Switch 101. Vehicle Data Recorder Port
40. Headlight High/Low Beam Switch 134. Map Light
43. 4-Way Hazard Switch 135. Handheld Spotlight
Windshield wipers should not be run on dry windows for an extended length of time as this will induce
higher than normal loads into the system and decrease the life of the motors, linkages, and wiper
blades substantially.
