Technical details
Operating Manual PNOZ m C0
1006013-EN-02
| 31
Inputs
Potential isolation No
Semiconductor outputs
Number of positive-switching single-pole semicon-
ductor outputs 4
Switching capability
Voltage 24 V
Current 2 A
Permitted current range 0,000 - 2,400 A
Residual current at "0" signal 0,05 mA
Max. transient pulsed current 4 A
Max. capacitive load 1 µF
Max. internal voltage drop 500 mV
Max. duration of off time during self test 400 µs
Switch-off delay 1 ms
Potential isolation No
Short circuit-proof yes
Test pulse outputs
Number of test pulse outputs 2
Voltage 24 V
Current 0,1 A
Max. duration of off time during self test 4 ms
Short circuit-proof yes
Potential isolation No
USB interface
Connection Mini-B socket
Max. cable length 3 m
Times
Simultaneity in the two-hand circuit 0,5 s
Processing time 5 ms
Environmental data
Ambient temperature
In accordance with the standard EN 60068-2-14
Temperature range 0 - 65 °C
Forced convection in control cabinet off 55 °C
Storage temperature
In accordance with the standard EN 60068-2-1/-2
Temperature range -25 - 70 °C
Climatic suitability
In accordance with the standard EN 60068-2-30, EN 60068-2-78
Condensation during operation Not permitted
Max. operating height above sea level 2000 m
EMC EN 61131-2
