Function description
Operating Manual PNOZ m1p (ETH)
20878-EN-16
14
4.4 Diagnostics
The status and error messages displayed by the LEDs are saved in an error stack. This er-
ror stack can be read from the PNOZmulti Configurator via the interfaces (RS232 or Ether-
net). More comprehensive diagnostics are possible via the interfaces or one of the fieldbus
modules, e.g. the PROFIBUS module.
4.5 Cascading
The cascading inputs and outputs enable several PNOZmulti and PNOZelog units to be
connected in series or as a tree structure.
INFORMATION
Detailed information on these functions and connection examples can be
found in the online help for the PNOZmulti Configurator and in the
PNOZmulti Installation Manual.
4.6 Safety mat, muting
INFORMATION
Detailed information on these functions and connection examples can be
found in the online help for the PNOZmulti Configurator and in the docu-
ment entitled "PNOZmulti - Special Applications".
4.7 Interfaces
The product PNOZ m1p ETH has two Ethernet interfaces, the product PNOZ m1p has one
serial interface to
} Project download
} Read the diagnostic data
} Set virtual inputs for standard functions
} Read virtual outputs for standard functions.
Information on diagnostics via the interfaces can be found in the document "PNOZmulti
communication interfaces".
The connection to Ethernet is made via the two 8-pin RJ45 sockets.
The Ethernet interface is configured in the PNOZmulti Configurator and is described in the
online help for the PNOZmulti Configurator.

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
