Operating Manual PNOZ m1p (ETH)
20878-EN-16
42
10 Order reference
10.1 Product
Product type Features Order no.
PNOZ m1p Base unit 773 100
PNOZ m1p coated ver-
sion
Base unit, coated version 773 105
PNOZ m1p ETH Base unit, Ethernet interface 773 103
PNOZ m1p ETH coated
version
Base unit, Ethernet interface, coated version 773 104
10.2 Accessories
Connection terminals
Product type Features Order No.
Set spring terminals 1 set of spring-loaded terminals 783 100
Set screw terminals 1 set of screw terminals 793 100
Terminator, jumper
Product type Features Order No.
PNOZmulti bus terminator Terminator 779 110
PNOZmulti bus terminator
coated
Terminator, coated version 779 112
KOP-XE Jumper 774 639
KOP-XE coated Jumper, coated version 774 640

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
