Pilz PNOZ m1p User Manual

Overview
Operating Manual PNOZ m1p (ETH)
20878-EN-16
8
} LED indicator for:
– Diagnostics
– Supply voltage
– Output circuits
– Input circuits
} Test pulse outputs used to monitor shorts across the inputs
} Monitoring of shorts between the safety outputs
} Expansion modules can be connected
(please refer to the document "PNOZmulti System Expansion" for details of the type
and number that can be connected)
} Integrated interfaces:
– PNOZ m1p: Serial interface RS232
– PNOZ m1pETH: 2 Ethernet interfaces
} Plug-in connection terminals:
Either spring-loaded terminal or screw terminal available as an accessory (see order
reference)
} Coated version:
Increased environmental requirements (see Technical details [ 30])
2.3 Chip card
To be able to use the product you will need a chip card.
Chip cards are available with memories of 8 kByte and 32 kByte. For large-scale projects
we recommend the 32 kByte chip card (see Technical Catalogue: Accessories chapter).

Pilz PNOZ m1p Specifications

General

Supply Voltage	24 V DC
Number of Safe Inputs	20
Number of Safe Outputs	8
Number of Standard Outputs	4
Protection Type	IP20
Expansion Modules	Yes
Safety Category	EN ISO 13849-1: PL e
Communication Interface	Ethernet
Operating Temperature Range	-20°C to +60°C
Dimensions (W x H x D)	45 mm x 121 mm
Standards	EN ISO 13849-1, EN 62061, EN 61508
