13
PDP-433CMX
Mark No. Description Part No.
1 DIGITAL VIDEO Assy AWV1971
2 X DRIVE Assy AWV1985
3 MX AUDIO Assy AWZ6644
NSP 4 Metal Fitting ANG2464
NSP 5 Heat Sink ANH1594
6 Silicone Sheet AEH1039
7 • • • • •
8 Audio Sheet (43) AMR3285
9 Rivet BEC1066
10 • • • • •
11 Coil Silicone Sheet AEH1048
12 Circuit Board Spacer AEC1872
13 Screw ABZ30P060FMC
14 Screw VBB30P100FNI
15 Screw PMB30P060FNI
•
UNDER LAYER SECTION (3) PARTS LIST
