Pioneer PDP-433CMX Service Manual
5
of 1
of 1 rating
177 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
15
PDP-433CMX
1
Y DRIVE Assy
AWZ6748
2
Circuit Board Spacer
AEC1872
3
•
•
•
•
•
4
•
•
•
•
•
5
Scan IC Spring (43L)
ABK1029
6
Scan IC Spring (43R)
ABK1030
7
Scan Insulation Sheet (43)
AMR3287
8
Screw
VBB30P100FNI
9
Screw
PMB30P060FNI
10
Coil Silicone Sheet
AEH1048
•
UNDER LAYER SECTION (4) PARTS LIST
Mark No. Description Part No.
14
16
Table of Contents
Default Chapter
1
Plasma Display
1
Safety Information
2
Product Safety Notice
3
Table of Contents
6
1 Specifications
7
2 Exploded Views and Parts List
8
Packing
8
Under Layer Section(1)
10
Under Layer Section(2)
11
Under Layer Section(3)
12
Under Layer Section(4)
14
Under Layer Section(5)
16
Under Layer Section(6)
18
Middle Layer Section(1)
20
Middle Layer Section(2)
21
Middle Layer Section(3)
22
Middle Layer Section(4)
23
Upper Layer Section(1)
24
Upper Layer Section(2)
26
Front Case Section
28
Rear Section
29
Pdp Service Assy 433(Awu1069)
30
Panel Chassis(43) Assy(Awu1067)
30
3 Block Diagram and Schematic Diagram
32
Block Diagram
32
Overall Block Diagam
32
Digital Video Assy
36
Driver Assy
37
Y Drive Assy
38
MX Audio Assy
40
SUB ADDRESS a and B ASSYS
41
Adr Resonance Assy
42
ADR CONNECT A, B, C and D ASSYS
42
Video Signal Route
43
Sync Signal Route
44
Waveforms
45
4 Pcb Connection Diagram
54
5 Pcb Parts List
54
6 Adjustment
68
Service Factory Mode
68
State Transition Diagram
68
Table of Adjustment Items in Service Factory
71
Description of Service Factory Menu Display
73
Adjustment Required When the Set Is Repared or Replaced
103
Adjustment
104
Video Card Adjustment
104
Commands
111
RS-232C COMMANDS (for Adjustment)
111
RS-232C COMMANDS (for Setting)
112
7 General Information
124
Diagnosis
124
Configuration of the Pc Board
124
Diagnosis for Shutdown and Power-Down by Led
125
Automatic Backup of Digital Video Assy Data
135
Disassembly
137
IC Information
141
8 Panel Facilities
172
Main Unit
172
Connection Panel
173
Remote Control Unit
175
Installation of the Unit
176
Other manuals for Pioneer PDP-433CMX
Technical Manual
192 pages
Quick Reference Parts Lists
12 pages
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Pioneer PDP-433CMX and is the answer not in the manual?
Ask a question
Pioneer PDP-433CMX Specifications
