27
PDP-433CMX
1 SW Power Supply Module AXY1059
2 • • • • •
3 J104 Wire W ADX2786
4 J119 13P Housing Wire ADX2768
5 J105 Wire B ADX2692
6 J101 12P Housing Wire ADX2771
7 J118 Wire L ADX2763
8 J103 13P Housing Wire ADX2779
9 J102 Wire PE ADX2738
10 Screw AMZ30P060FZK
11 • • • • •
12 Solder Warning Label See Contrast table (2)
(1) UPPER LAYER SECTION (2) PARTS LIST
Mark No. Description Part No.
(2) CONTRAST TABLE
PDP-433CMX/LUCB and PDP-433MXE/YVLDK are constructed the same except for the following :
Mark No. Symbol and Description
Part No.
Remarks
PDP-433CMX PDP-433MXE
LUCB YVLDK
12
Solder Warning Label AAX2644 Not used
To Next Page
