Pioneer PDP-433CMX

Mark No. Description Part No. Mark No. Description Part No.
58
PDP-433CMX
TRANSFORMER
T3701 ATK1153
CAPACITORS
C3701 (22µF/315V) ACH1345
C3717 (47µF/315V) ACH1346
C3704 CEHAT101M16
C3706,C3711,C3714 CEHAT101M25
C3712 CEHAT331M16
C3705 CKSQYF104Z50
C3703,C3707,C3708,C3710 CKSRYB104K16
C3715,C3716 CKSRYB104K16
RESISTORS
VR3701 (1kΩ) ACP1089
R3732 RS1/16S1001F
R3806 RS1/16S1802F
R3701-R3704,R3706-R3717 RS1/16S1803F
R3805 RS1/16S2702F
R3731 RS1/16S3900F
R3802 RS1/16S5601F
R3738,R3739 RS1/2S102J
R3800,R3801 RS1/2S823J
Other Resistors RS1/16S J
Y DRIVE ASSY
[Y DRIVE LOGIC BLOCK]
SEMICONDUCTORS
IC2006 PE1013B
IC2007 TC74ACT540FT
IC2001,IC2003-IC2005 TC74ACT541FT
IC2101 TLP181(GR)
Q2101,Q2102 HN1C01FU
D2101 1SS355
COIL
L2001 LFEA100J
CAPACITORS
C2101 CEHAT100M50
C2103 CEHAT1R0M50
C2003 CEHAT470M16
C2001,C2004,C2005,C2007,C2008 CKSRYF104Z50
C2010,C2102,C2104,C2122 CKSRYF104Z50
RESISTORS
R2015-R2018 RAB4C0R0J
R2001,R2002,R2005,R2011 RAB4C470J
R2037,R2038 RAB4C470J
R2035,R2036,R2039,R2040 RAB4C472J
Other Resistors RS1/16S J
OTHERS
CN2001 50P CONNECTOR AKM1201
2101 SENSOR AXX1057
2001 Screw BMZ20P040FMC
2002 Nut NB20FMC
[Y DRIVE SUS BLOCK]
SEMICONDUCTORS
IC2202,IC2208 HCPL-M611
IC2206,IC2214 STK795-470
IC2201 TC74ACT541FT
IC2203,IC2204,IC2210,IC2212 TND301S
IC2213,IC2216,IC2217 TND301S
IC2205,IC2209 UPC78L05T
Q2203 2SJ281
Q2204,Q2205 2SJ522
Q2201 2SK2503
Q2215,Q2217-Q2221,Q2226,Q2227 FQB34N20
Q2232,Q2233 FQB34N20
Q2210,Q2211 FS16VS-9
Q2209 HN1B04FU
D2225 1SS184
D2202,D2204 1SS226
D2211 1SS355
D2201 D1FL20U(S)
D2203,D2205,D2214,D2216,D2223 D1FL40
D2226, D2227, D2243 D1FL40
D2209 DF20L60
D2208,D2210,D2212,D2215 EC11FS4
D2221,D2222,D2228,D2239 EC11FS4
D2224,D2229 RB751V-40
D2206,D2207 UDZ15B
COILS
L2207 RADIAL LEAD INDUCTOR ATH1110
L2213,L2214 ATH1112
RADIAL LEAD INDUCTOR
L2206,L2211 CHOKE COIL ATH1113
L2208,L2212,L2215,L2216 ATH1118
CHOKE COIL
L2210 LFEA100J
L2203,L2205 LFEA101J
L2201 LFEA470J
CAPACITORS
C2228,C2230,C2231,C2250-C2252 ACE1160
(1.5µF)
C2209,C2210 (0.1µF/630V) ACG1092
C2233,C2248 (100pF500V) ACG1104
C2211 (47µF/350V) ACH1346
C2216,C2217,C2219,C2234-C2236 ACH1352
(330µF315)
C2221,C2225 CEHAT101M16
C2204,C2227,C2237,C2240,C2247 CEHAT101M25
C2202 CEHAT221M25
C2232 CEHAT331M2A
C2218,C2224,C2229 CEHAT470M16
C2212,C2214 CEHAT470M25
C2264,C2270 CKSRYB472K50
C2201,C2203,C2205,C2208,C2213 CKSRYF104Z50
C2220,C2222,C2223,C2238,C2239 CKSRYF104Z50
C2241,C2242 CKSRYF104Z50
RESISTORS
VR2201,VR2205 (1kΩ) ACP1089
R2235,R2273,R2291,R2305,R2315 RAB4C100J
R2317,R2342 RAB4C100J
R2253,R2256,R2270,R2283,R2332 RS1/10S184J
