Page #67 background imageLoading...
Page #67 background image
Mark No. Description Part No. Mark No. Description Part No.
67
PDP-433CMX
IR ASSY
SEMICONDUCTORS
Q8551 2SC2712
D8552 1SS226
D8551 1SS355
CAPACITORS
C8551 CEV470M6R3
C8553 CKSQYB472K50
C8552 CKSRYB103K50
C8554 CKSRYF104Z16
RESISTORS
All Resistors RS1/16S J
OTHERS
8551 REMOTE RECEIVER UNIT GP1UM26RK
KEY CONNECTOR ASSY
SEMICONDUCTORS
IC8301 PD5719A
Q8301 2SC2712
D8304-D8310 1SS226
D8301,D8303 1SS355
D8302 RD3.0MB
CAPACITORS
C8303 CEAT2R2M50
C8304 CKSRYB103K50
C8301,C8302,C8305 CKSRYB472K50
RESISTORS
R8315 RAB4C182J
Other Resistors RS1/16S J
OTHERS
CN8302 8P FFC CONNECTOR AKM1207
CN8301 PH CONNECTOR B4B-PH-SM3
X8301 CERALOCK (3.84MHz) ASS1162
