2. INFORMATION
Basic Operation
• Display the state of each item
Operating specifications
• When this mode is entered, the VERSION display (the function called by pressing the "1" key) is displayed first.
• When any of the above keys are pressed, the corresponding operation is executed.
Note: The VERSION display is the default display for Service Factory mode.
Rem Code Key Name Function & Display Description Remarks
Lower
Layer
AA01 1 VERSION
Display of
information for
each item
Main, Wide, module and panel
microcomputers : Ver
Wide flash (OSD) / Panel flash (Sequence) : Ver
×
AA02 2 PD INFO Past eight times / Place (1st, 2nd) / Time Stamp ×
AA03 3 NG INFO
AUDIO/FAN/MODULE/PANEL/WIDE/
MAIN IIC/MODULE IIC/DEW
×
AA04 4 TEMPERATURE 1/2/3/FAN output ×
AA05 5 MEMO Display MEMO ×
AA06 6
AA07 7
AA08 8
AA09 9
AA00 10
AA46 11
AA47 12
AA4D BS1
AA4E BS3
AA4F BS5
AA50 BS7
AA51 BS9
AA52 BS11
AA53 BS13
AA54 BS15
AA96 5
Selection of upper items
AA97 ∞ Selection of lower items
AA94
AA95
AA8A SET
AAD3-AF70
AA4A
AUDIO
DISPLAY CALL
Shifting to various
adjustment / setting
screen.
INFORMATION
AA1D SURROUND MODE RANGE CHECK
AA59
AA43
AV SELECT
AV MEMORY
REFERENCE
AA1E MPX OFFSET
AAD3-AF3C SCREEN SIZE VIDEO OPTION
AAD3-AF36
AAD3-AF22
FULL AUTO ZOOM
P.ZOOM
INITIALIZE
AA49 MUTING
Shifting to next adjust-
ment / setting screen.
RANGE CHECK
INFO
VERS
––S1 I N4– 02– ∗
∗∗∗
2NT
ION
MA I N UCOM :
:
:
:
:
:
∗∗∗
WI DE UCOM
∗∗∗
WI DE FROM
∗∗∗
MODU UCOM
∗∗∗
PANE UCOM
∗∗∗
PANE FROM
#1
1
5
10
15
16
1 5 10 15 20 25 30 32
