93
PDP-433CMX
5
678
5
6
7
8
C
D
F
A
B
E
: To select YES or NO
SET : When YES is selected, the SET DATA are stored
in memory, and the initial display appears.
When NO is selected, NOW DATA is
maintained, and the initial display appears.
• If this setting screen is displayed when the unit is shifted from another mode, the COLOR DET display (the function called by pressing the
"1" key) is displayed first. If the unit is shifted back from a lower-layer display of this setting screen, the originally selected item will be
displayed.
• When any of the above keys is pressed, the corresponding operation is executed.
• As for the following items, the adjusted values will be stored in memory: COLOR DET., ACL SW, INTE. MODE, MEMO, VIDEO
STANDARD, PC STANDARD, VIDEO MODE 1, PC MODE 1, HOURMETER SET, PULSEMETER SET, FINAL SETUP, MASK 1, MASK 2,
and PICTURE DEFAULT.
1. COLOR DET. : The color detection system is set.
2. EEP CHECK: EEPROM writing is checked.
The rightmost two digits in hexadecimal notation from the results of addition of data at subaddresses 1760-177C (PDC XGA/SHARP data) of the
EEPROM are displayed.
3. ACL SW: The ACL is set.
4. INTEGRATOR MODE: The integrator protection is set.
5. P&P WRITE ENA: The writing permission of the EEPROM for Plug & Play is set.
6. HOURMETER SET: The hourmeter is displayed and set.
7. PULSEMETER SET: The pulse meter is displayed and set.
EURO SA ALL
Operating specifications
Function description
The upper three digits of SET DATA can be changed:
5∞ : To select numbers
: To select one of the upper three digits to be
changed
SET : To register the setting and shift to the
confirmation screen for setting changes.
The upper three digits of SET DATA can be changed:
5∞ : To select numbers
: To select one of the upper three digits to be
changed
SET : To register the setting and shift to the
confirmation screen for setting changes.
INIT
H
NOW DATA : 1 2 34 5H
SET DATA: 09700H
OUR EMTERSET
––S1 I N4– 02– ∗2NT#1
INIT
P
NOW DATA : 1 2 34 5 6.7G
SET DATA: 09700 0.0G
ULS MEETRESET
––S1 I N4– 02– ∗2NT#1
INIT
H
NOYES
OUR EMTERSET ?
––S1 I N4– 02– ∗2NT#1
1
5
10
15
16
1 5 10 15 20 25 30 32
1
5
10
15
16
1 5 10 15 20 25 30 32
1
5
10
15
16
1 5 10 15 20 25 30 32
