Pioneer PDP-433CMX

127
Before Beginning Adjustments
PICTURE CONTRAST –30 to +30 x 3 0 ???
BRIGHT. –30 to +30 x 3 0 ???
R.LEVEL 0 to +60 x 3 +60 ?
G.LEVEL 0 to +60 x 3 +60 ?
B.LEVEL 0 to +60 x 3 +60 ?
H.ENHANCE 0 to +15 x 1 0 ?
V.ENHANCE 0 to +15 x 1 0 ?
COLOR –30 to +30 x 3 0 ??
TINT –30 to +30 x 1 0 ??
SHARP –7 to +7 x 1 0 ??
SCREEN POSITION H.POSITION –128 to +127 x 1 0 ?
V.POSITION –128 to +127 x 1 0 ?
CLOCK/ CLOCK –128 to +127 x 1 0
PHASE PHASE –32 to +31 x 1 0
SET UP
INPUT LABEL
Max. 8 letters
(Note 6)
???
&INPUT
*
&
POWER MANAGEMENT OFF–ON OFF ?
AUTO POWER OFF OFF–ON OFF ??
COLOR TEMP
LOW – MID LOW – MIDDLE
MIDDLE ??
– MID HIGH – HIGH
DIGITAL NR OFF – LOW – MIDDLE – HIGH LOW ??
HIGH CONTRAST OFF – ON OFF ??
PURECINEMA OFF – STANDARD – HQ OFF % (Note 1) % (Note 1)
COLOR SYSTEM
AUTO – NTSC – PAL
AUTO ??
– SECAM – 4.43NTSC
CLAMP POSITION AUTO – LOCKED AUTO
3D Y/C MODE STILL – MOTION MOTION % (Note 2)
SETTING
VGA – WIDE VGA – VIDEO (Note3) 1 VGA
% (Note 3)
XGA – WIDE XGA (Note3) 2 XGA
VIDEO SIGNAL RGB – COMPONENT RGB
OPTION POWER CONTROL STANDARD – MODE1 – MODE2 STANDARD ?
(Note 4) AUTO FUNCTION OFF – INPUT1 – INPUT4 (Note 4) OFF ?
AUDIO OUT FIXED – VARIABLE FIXED ?
7 PDA-5002A★ (applies only when equipped with PDA-5002)
Variable Range
(STEP)
Coefficient
(/STEP)
Factory
Preset
PDA-5002
INPUT3 INPUT4
Video signal Video signal
PC signal
S-video
Digital RGB
Composite
INPUT5
(Note 1) PURECINEMA can be set only during input of 525i (480i), NTSC, and 4.43NTSC signals.
(Note 2) 3D Y/C MODE setting can be done only when all the following conditions are satisfied.
When INPUT 4 is selected
When the NTSC signal is entered while the COLOR SYSTEM is set to AUTO
Or when COLOR SYSTEM is set to NTSC.
(Note 3) 1 It is set when vertical frequency 60Hz and horizontal frequency 31.5 kHz signals are entered. VIDEO cannot be set when
digital RGB is entered or when a video card is not mounted.
2 It is set when vertical frequency 60Hz and horizontal frequency 48.4 kHz or when vertical frequency 70 Hz and horizontal
frequency 56.6 kHz signals are entered.
(Note 4) OPTION is set the same for all inputs.
(Note 5) When the PDA-5002 is not mounted, INPUT 4 cannot be set.
(Note 6)
*
Based on 1 to 5/input functions.
