Controls and Connectors
7 INPUT2 (BNC jacks)
For connection of components that have RGB or
component
★
(applies only when equipped with PDA-
5002) output jacks such as a personal computer,
DVD player, or external RGB decoder.
8 Synchronizing signal impedance selector switch
Depending on the connections made at INPUT2, it
may be necessary to set this switch to match the
output impedance of the connected component’s
synchronization signal.
When the output impedance of the component’s
synchronization signal is below 75 Ω, set this switch
to the 75 Ω position.
9 AUDIO INPUT (Stereo mini jack)
Use to obtain sound when INPUT1, INPUT2 or
INPUT5
★
(applies only when equipped with PDA-
5002) is selected.
Connect this jack to the audio output connector of the
device connected to the plasma display’s INPUT1 or
INPUT2, or to the audio output connector of the
device connected to the video card’s INPUT5
★
(applies only when equipped with PDA-5002).
0 AUDIO OUTPUT (Stereo mini jack)
Use to output the audio of the selected source
component connected to the main unit to an AV
amplifier or similar component.
- MAIN POWER switch
Use to switch the main power or the main unit on
and off.
= AC INLET
A power cable is furnished with the main unit:
connect one end of the power cable to this
connector and the other end to a standard AC
power source.
~ SPEAKER (L) terminal
For connection of an external left speaker. Connect
a speaker that has an impedance of 8 -16 Ω.
Video Card <PDA-5002> Section ★
(applies only when equipped with PDA-5002)
! INPUT5 (DVI-D jack)
Use to connect a computer.
Note: This unit does not support the display of
copyguard-protected video signals.
@ AUDIO INPUT3 (RCA Pin jacks)
Use to obtain sound when INPUT3 is selected.
Connect these jacks to the audio output connectors
of components connected to the video card’s
INPUT3.
Note: The left audio channel (L) jack is not
compatible with monaural input sources.
# INPUT3 (S-video jack)
For connection of components that have an S-video
output jack such as a video deck, video camera,
laser disc player, or DVD player.
$ AUDIO INPUT4 (RCA Pin jacks)
Use to obtain sound when INPUT4 is selected.
Connect these jacks to the audio output connectors
of components connected to the video card’s
INPUT4.
Note: The left audio channel (L) jack is not
compatible with monaural input sources.
% INPUT4 (BNC jack)
For connection of components that have a
composite video output jack such as a video deck,
video camera, laser disc player, or DVD player.
^ OUTPUT (INPUT4) (BNC jack)
Use the OUTPUT (INPUT4) jack to output the video
signal to an external monitor or other component.
Note: The video signal will not be output from the
OUTPUT (INPUT4) jack when the main power of
this display is off or in standby mode.
