178
STX ID <PON> <AJY> <CNT> ETX
STX ID <POF> <PON> ETX
STX ID <IN2> <AJY> <CNT> ETX
STX ID <GWB> <CNT> ETX
Error Example 1)
Error Example 2)
Error Example 3)
RS-232C Adjustment Mode
(Note) Transmit the following commands one at a time.
Transmit the next command after waiting at least the following waiting times
Power ON/OFF commands
Command Function Waiting time (seconds)
PON Perform power ON 6
POF Perform power standby 6
Function switching command
Command Function Waiting time (seconds)
IN1 ~ IN5 Function switching 3
Commands accompanying signal mode switching
Command Function Waiting time (seconds)
BBY Set the input setting to VIDEO:RGB 3
PCY Set the input setting to PC (VGA or XGA) 3
PWY Set the input setting to PC (WVGA or WXGA) 3
CP1 Set the input setting toVIDEO:COMPONENT1 3
CP2 Set the input setting toVIDEO:COMPONENT2 3
TVA Set the color system to AUTO 3
NTS Set the color system to NTSC 3
PAL Set the color system to PAL 3
SCM Set the color system to SECAM 3
NT4 Set the color system to 4.43NTSC 3
GET commands
Command Function Waiting time (seconds)
GPS Output position adjustment data to TXD 2
GWB Output picture and white balance data to TXD 2
GSS Output SET UP setting to TXD 2
GSO Output the OPTION setting to TXD 2
Error Example 4)
