Special Installation (Mounting to fittings)
35 mm or
less
Attach so that
the fan is on
the left side
viewed from
the rear.
Example 1
Example 2
Example 3 Example 4
35 mm or
less
Example 5 Example 6
35 mm or
less
Example 7 Example 8
35 mm or
less
Vertical installation
Standard installation
(Note that only Examples 2 and 3 apply in cases where top and bottom are reversed)
[503CMX/503MXE]
