Special Installation (Place product upright and flush into wall (embedding in the wall))
Methods of Securing: Basic methods of securing are shown below. Avoid blocking or covering areas aside from those
indicated by
. The methods indicated by a large X-mark must not be used.
Before attaching the unit to fittings, double-check that the thickness and height of the fittings,
and the number of fixing bolts is correct.
(Also refer to 3.5.1 “Mounting to fittings”.)
[503CMX/503MXE]
To Next Page
