PDP-507XD
111
5678
56
7
8
C
D
F
A
B
E
Terminal Panel B (50E)
3
1
Remove the 12 screws.
2
Remove the 10 screws.
3
Remove the four screws.
4
Remove the terminal panel B (50E).
4
Terminal panel B (50E)
TANSHI Assy
SP TERMINAL Assy
2
×12
1
2
2
2
2
2
2
3333
2
22
Front Case Assy (507PE)
4
1
Remove the four rivets.
Turn it not to press the rivet.
(Because when the rivet presses, fit in once again.)
Rivet
2
Pull the lower part of the Front case Assy (507PE)
toward you and out.
3
Remove the Front case Assy (507PE), by pulling
it upward.
2
1
3
Front case Assy (507PE)
1
1
1 1
