Pioneer PDP-507XD Service Manual

PDP-507XD
29
5678
56
7
8
C
D
F
A
B
E
C 3445–3448 CKSSYB104K10
[ADDRESS CN BLOCK]
SEMICONDUCTORS
Q 3501,3502 RN1901
D 3501,3502 DAN202U
MISCELLANEOUS
CN 3501–3504,3506 AKM1348
CN 3505 VKN1310
RESISTORS
R 3519,3520 RAB4C472J
R 3521,3522,3525 RAB4C101J
R 3524 RAB4C222J
Other Resistors RS1/16SS###J
[DIGITAL DD CON BLOCK]
SEMICONDUCTORS
IC 3601 BA80BC0WFP
MISCELLANEOUS
U 3601 AXY1137
RESISTORS
R 3611 RAB4C101J
Other Resistors RS1/16SS###J
CAPACITORS
C 3609 CKSSYB104K10
C 3611 CKSQYB105K16
C 3612 ACH1394
C 3613 CKSSYB103K16
SENSOR ASSY
SEMICONDUCTORS
IC 3651 MM1522XU
IC 3652 BR24L02FJ-W
Q 3651 HN1B04FU
MISCELLANEOUS
CN 3651 AKM1276
All Resistors RS1/16SS###J
CAPACITORS
C 3651,3653 CKSRYB105K6R3
C 3652,3654 CKSSYB103K16
C 3656,3657 CKSSYB104K10
50 X MAIN DRIVE ASSY
[50X LOGIC BLOCK]
SEMICONDUCTORS
IC 1001 TC74ACT541FT
IC 1002 TC74VHC00FTS1
D 1001–1004 1SS355
MISCELLANEOUS
K 1004,1007 AKX1061
CN 1001 VKN1310
RESISTORS
R 1001,1006 RAB4C470J
Mark No. Description Part No.
R 1004 RAB4C472J
VR 1001 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C 1001 CEHAT470M16
C 1002,1003 CKSRYB104K16
C 1004 CCSRCH331J50
C 1006 CCSRCH680J50
[50X RESONANCE BLCOK]
SEMICONDUCTORS
IC 1101,1105 TND307TD
IC 1102 PS9117P
IC 1104 AXF1163
IC 1107 PS2701A-1(L)
Q 1101 2SC2412K
Q 1102,1103 QSZ2
Q 1104,1105 2SC4081
D 1101,1103 UDZS5R6(B)
D 1102 CRH01
D 1104 UDZS15(B)
MISCELLANEOUS
L 1101 ATH1217
L 1106 ATH1216
F 1101 CTF1449
1101 ANH1653
1102A EH1092
1103 BMZ30P080FTC
RESISTORS
R 1107,1108 RS3LMF100J
R 1109,1110 RS1/10S4702F
R 1113 RS1/16S1002F
R 1114 RS1/16S3302F
R 1115 ACN1259
R 1119 ACN1258
R 1121 RS1/16S4701F
Other Resistors RS1/16S###J
CAPACITORS
C 1101,1114 CEHAT470M25
C 1102,1115 CKSRYF104Z50
C 1103 CKSRYB104K16
C 1104,1117 CKSYB105K25
C 1107,1116 ACG1126
C 1113 ACH1450
C 1121–1124 ACE1178
[50X SUS BLOCK]
SEMICONDUCTORS
IC 1201,1204,1206,1208 TND307TD
IC 1202,1205 PS9117P
IC 1209 MM1565AF
Q 1201,1208 2SC2412K
Q 1202,1204,1205,1207 H5N2512LS
Q 1209,1212–1214 QSZ2
Q 1210,1211 FKP280AS
Q 1215,1221 FKP300AS
Q 1216 DTC143EK
Q 1217 DTC123TKA
Mark No. Description Part No.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
