Pioneer PDP-507XD Service Manual

PDP-507XD
30
1234
1234
C
D
F
A
B
E
Q 1220 R5009ANJ
D 1201,1205 UDZS5R6(B)
D 1202,1203,1206,1211 CRH01
D 1204 D1FL40
D 1208 1SS302
D 1209 UDZS16(B)
D 1210 1SS355
D 1212 CRH01
D 1213 UDZS8R2(B)
MISCELLANEOUS
L 1201,1203,1204 BTH1134
L 1202 ATH1186
F 1227 CTF1449
K 1202 AKX1061
KN 1201–1204,1210–1217 ANK1841
CN 1201 14PL-FJ
CN 1204 B8B-EH
1202 PMB30P080FNI
RESISTORS
R 1208,1210,1213,1215 RS1/10S100J
R 1211 ACN1254
R 1219,1228,1230,1231 RS1/10S0R0J
R 1220,1224,1233,1256 RS1/10S2R2J
R 1237 RS1/10S0R0J
R 1239 ACN1258
R 1245 ACN1257
R 1247,1248 RS3LMF470J
Other Resistors RS1/16S###J
CAPACITORS
C 1201,1212 ACG1126
C 1202,1209,1232,1236 CKSRYB104K16
C 1203,1208,1215,1229 CKSRYF104Z50
C 1205,1206,1217,1218 ACG1139
C 1207,1214,1220,1226 CEHAT470M25
C 1210,1211,1216,1241 CKSYB105K25
C 1213 CCSRCH221J50
C 1222,1223 ACH1423
C 1224,1225 ACE1178
C 1228 CEHAT2R2M2E
C 1230 ACH1449
C 1231,1237 CEHAT101M10
C 1233 CKSRYB473K16
C 1234 CEHAT470M16
C 1235 CKSRYB105K6R3
C 1244 CKSRYB104K25
[50X D-D CON BLOCK]
SEMICONDUCTORS
IC 1301 PS2701A-1(L)
IC 1302 TA76431FR
Q 1301 2SC2412K
Q 1303,1306,1307 HN1C01FU
Q 1304,1401 2SD1898
Q 1305 2SA1037K
Q 1402 2SC4081
D 1307 CRF03
D 1308,1403 UDZS5R1(B)
D 1309,1311,1401,1405 CRH01
D 1312,1402 1SS301
Mark No. Description Part No.
D 1313,1318,1404,1406 1SS355
D 1315,1316 UDZS4R7(B)
MISCELLANEOUS
T 1302 ATK1160
T 1401 ATK1159
RESISTORS
R 1312–1314,1317 RS1/10S224J
R 1328 RAB4C472J
VR 1301 CCP1392
Other Resistors RS1/16S###J
CAPACITORS
C 1301,1302,1405,1406 CKSRYB104K16
C 1308,1401,1407 CEHAT101M25
C 1310,1313,1402 CKSYB105K25
C 1311 ACH1451
C 1312,1403 CKSRYB103K50
C 1314 CEHAT100M50
C 1404 ACG1105
50 X SUB DRIVE ASSY
SEMICONDUCTORS
Q 1501 FKP280AS
Q 1502 FKP300AS
Q 1504,1505 H5N2512LS
Q 1507 QSZ2
D 1501 CRH01
MISCELLANEOUS
K 1501 AKX1061
KN 1501–1505 ANK1841
CN 1501 14R-FJ
1502 PMB30P080FNI
RESISTORS
R 1502,1503 RS1/10S2R2J
R 1507,1508 RS1/10S100J
Other Resistors RS1/16S###J
CAPACITORS
C 1501 ACE1178
C 1503,1504 ACG1139
C 1505 ACH1423
C 1506 CKSYB105K25
[DRIVE HEATSINK M]
MISCELLANEOUS
3001,3001 ANH1656
3101,3101 ANG2679
RESISTORS
All Resistors RS1/16S###J
50 Y MAIN DRIVE ASSY
[50Y LOGIC BLOCK]
SEMICONDUCTORS
IC 2001,2003 TC74ACT541FT
IC 2002 TC74ACT540FT
D 2001,2006,2007,2011 1SS355
D 2003–2005 1SS301
Mark No. Description Part No.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
