Pioneer PDP-507XD Service Manual

PDP-507XD
32
1234
1234
C
D
F
A
B
E
C 2218,2219,2224,2261 CKSYB105K25
C 2221 CCSRCH221J50
C 2223,2232 CKSRYF104Z50
C 2227,2231 CEHAT470M25
C 2234,2240 CEHAT2R2M2E
C 2237,2241 ACH1423
C 2238,2239 ACE1178
C 2244 ACH1449
C 2246 ACH1426
C 2247,2252 CEHAT101M10
C 2249 CKSRYB473K16
C 2250 CEHAT470M16
C 2251 CKSRYB105K6R3
C 2271,2276 CKSRYB104K25
[50Y VH D-D CON BLOCK]
SEMICONDUCTORS
IC 2401 BA10358F
IC 2402 MIP2E3DMU
IC 2403 PS2701A-1(L)
IC 2405,2412 TA76431FR
Q 2401 2SC3425
Q 2402 2SD2568
Q 2403 2SC4081
Q 2404 HN1C01FU
D 2402,2407 CRF03
D 2403 UDZS33(B)
D 2404 1SS355
D 2406,2410 UDZS4R7(B)
D 2408,2409 CRH01
D 2411 UDZS12(B)
MISCELLANEOUS
L 2401 BTH1136
T 2401 ATK1158
RESISTORS
R 2401,2402 RS1/10S104J
R 2403,2404,2406 RS1/10S2203F
R 2407,2410 RS1/16S5601F
R 2412 RS1/16S1003F
R 2413 RS1/16S1802F
R 2414,2415 RS1/16S4702F
R 2416 RS1/10S0R0J
R 2420,2421,2424 RS1/10S473J
R 2426 RAB4C472J
VR 2401 CCP1392
VR 2402 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C 2401 ACE1177
C 2402 ACH1425
C 2403,2404 CKSRYB104K25
C 2405,2407,2412 CKSRYB104K16
C 2408 CEHAT101M16
C 2409 CEHAT470M25
C 2410 CEHAT101M25
C 2411 ACH1450
C 2413 CEHAT221M16
C 2421 ACH1451
Mark No. Description Part No.
[50Y D-D CON BLOCK]
SEMICONDUCTORS
IC 2501,2502,2504 PS2701A-1(L)
IC 2503 BA10358F
IC 2506,2514 TA76431FR
Q 2501,2506,2511 2SD1898
Q 2502,2507 2SA1576A
Q 2503,2515 DTC143EUA
Q 2504,2509,2513 HN1C01FU
Q 2505 2SC2713
Q 2508 2SA2005
Q 2510 2SA1163
Q 2512,2514 2SC4081
Q 2520 2SC2412K
D 2501,2503,2510,2516 CRH01
D 2502,2512,2518 1SS301
D 2504,2508 UDZS4R7(B)
D 2505,2507,2513,2517 1SS355
D 2509 D1FL40
D 2511 1SS302
D 2515,2521 UDZS5R1(B)
D 2519,2520,2523 1SS355
D 2522 UDZS5R6(B)
D 2524 UDZS15(B)
MISCELLANEOUS
T 2501 ATK1156
T 2502 ATK1161
T 2503 ATK1159
RESISTORS
R 2510,2514,2539,2543 RS1/16S4701F
R 2513 RAB4C472J
R 2523 RS1/16S4702F
R 2524,2531 RS1/10S224J
R 2530,2532 RS1/16S1501F
R 2533 RS3LMF151J
R 2536 RS1/16S1002F
R 2544 RS1/16S4701F
R 2550 RS1/16S5601F
R 2554 RS1/16S6801F
VR 2501 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C 2501,2502,2514 CEHAT101M25
C 2503,2515 ACG1105
C 2504 CKSRYB102K50
C 2505,2506,2512 CKSRYB104K16
C 2507 CEHAT221M6R3
C 2508 CEHAT221M25
C 2509,2510,2518 CKSRYB103K50
C 2511,2516 CKSRYB105K6R3
C 2513 CKSYB105K25
C 2517 CKSRYF104Z50
C 2519–2521,2525 CKSRYB104K16
[50Y SCAN BLOCK]
SEMICONDUCTORS
IC 2601–2603,2607 TLP116
Mark No. Description Part No.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
