Pioneer PDP-507XD Service Manual

PDP-507XD
33
5678
56
7
8
C
D
F
A
B
E
IC 2604–2606 PS9117P
IC 2610,2611 TC74AC540FT
MISCELLANEOUS
L 2601,2611 BTH1134
CN 2601 AKM1200
RESISTORS
R 2624 RAB4C220J
R 2631 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C 2601,2623 CEHAT101M10
C 2602,2603,2611–2617 CKSRYB104K16
C 2621,2622 ACH1450
C 2631 CKSRYB104K16
50 Y SUB DRIVE ASSY
SEMICONDUCTORS
Q 2701 FKP280AS
Q 2711 FKP300AS
Q 2721,2723,2725,2726 H5N2512LS
Q 2731 QSZ2
D 2701 CRH01
MISCELLANEOUS
F 2701–2706 ATX1062
K 2701 AKX1061
KN 2701,2702,2711–2713 ANK1841
CN 2701 14R-FJ
2702 PMB30P080FNI
RESISTORS
R 2702,2712 RS1/10S2R2J
R 2722,2724,2726,2727 RS1/10S100J
R 2732 RS1/10S0R0J
Other Resistors RS1/16S###J
CAPACITORS
C 2701 ACE1178
C 2702 ACH1423
C 2703 ACG1088
C 2711,2721 ACG1139
C 2731 CKSYB105K25
[DRIVE HEATSINK M]
MISCELLANEOUS
3001,3001 ANH1656
3101,3101 ANG2679
RESISTORS
All Resistors RS1/16S###J
MAIN ASSY
[BOARD IF BLOCK]
SEMICONDUCTORS
IC 4001–4005 TC74VCX541FT
Q 4001,4002,4005 DTC124EUA
Q 4003,4004 RN2902
MISCELLANEOUS
L 4001–4006 BTX1042
>
F 4001–4010 CTF1557
Mark No. Description Part No.
CN 4001,4004,4005 AKM1349
CN 4006 KM200NA6
CN 4013 AKM1353
CN 4014 AKM1354
CN 4018 AKM1233
RESISTORS
R 4001 RAB4CQ470J
R 4021-4024 BCN1067
R 4030,4031,4035 RS1/16S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 4001–4003,4007,4009 CKSSYF104Z16
C 4004 CCSSCH101J50
C 4006,4036,4039 DCH1201
C 4008 DCH1165
C 4014 CKSSYF104Z16
C 4033,4051 CKSRYF104Z50
C 4048-4050 CCSSCH470J50
[REG 0 BLOCK]
SEMICONDUCTORS
IC 4101,4114,4115 S-1132B18-U5
IC 4102 LTC3414EFE
IC 4103 LTC3412EFE
IC 4104,4111,4113 NJM2846DL3-05
IC 4105 S-1170B25UC-OTK
IC 4106 S-1170B15UC-OTA
IC 4107 NJM2846DL3-33
IC 4108 NJM2846DL3-18
IC 4109,4110 PQ090DNA1ZPH
Q 4101,4103 RN1902
Q 4102 HN1C01FU
Q 4104 DTC124EUA
Q 4105,4106 UPA1917TE
Q 4107–4109 2SC4116
Q 4110 2SD2114K
D 4101–4110,4112–4118 1SS355
D 4111,4120,4122 1SS357
D 4121 1SS355
MISCELLANEOUS
L 4101,4103 BTX1042
L 4102,4105–4107 BTX1039
L 4108 ATH1208
L 4109 ATH1194
F 4101,4102 VTF1080
J 4101,4102 ADX3513
RESISTORS
R 4113,4134–4136,4140 RS1/10S0R0J
R 4119,4131,4146 RS1/16SS3003F
R 4120 RS1/16SS2003F
R 4123,4159 RS1/16SS1502F
R 4124 RS1/16SS6202F
R 4133 RS1/16SS1503F
R 4148,4164–4170,4173 RS1/10S0R0J
R 4157 ACN1268
Other Resistors RS1/16SS###J
CAPACITORS
Mark No. Description Part No.

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
