Pioneer PDP-507XD Service Manual

PDP-507XD
66
1234
1234
C
D
F
A
B
E
R07 DT Assy MAIN Assy
CN4000 (AKM1348)
Voltage
(V)
CN4014 (AKM1354)
No. Pin Name Pin Name No.
1 GND 0 GND 40
2 GND 0 GND 39
3 GND 0 GND 38
4 GND 0 GND 37
5 GND 0 GND 36
6 GND 0 GND 35
7 DT_SP_R 0 DT_SP_R 34
8 GND 0 GND 33
9 DT_SP_L 0 DT_SP_L 32
10 GND 0 GND 31
11 OPT_R 0 OPT_R 30
12 GND 0 GND 29
13 OPT_L 0 OPT_L 28
14 GND 0 GND 27
15 DT_MON_C 1.7 DT_MON_C 26
16 GND 0 GND 25
17 GND 0 GND 24
18 DT_MON_Y 1.7 DT_MON_Y 23
19 GND 0 GND 22
20 GND 0 GND 21
21 GND 0 GND 20
22 GND 0 GND 19
23 GND 0 GND 18
24 GND 0 GND 17
25 GND 0 GND 16
26 GND 0 GND 15
27 NOT_USE 0 NC 14
28 GND 0 GND 13
29 GND 0 GND 12
30 NOT_USE 0 NC 11
31 GND 0 GND 10
32 GND 0 GND 9
33 NOT_USE 0 NC 8
34 GND 0 GND 7
35 GND 0 GND 6
36 ANT_POW_EU 0 ANT_POW_EU 5
37 POW_DET 0 POW_DET 4
38 RST_DT 3.3 RST_DT 3
39 DT_DET 0 DT_DET 2
40 GND 0 GND 1
AUDIO Assy MAIN Assy
R07 DT Assy MAIN Assy
CN6000 (AKM1298)
Voltage
(V)
CN4017 (KM200NA12)
No. Pin Name Pin Name No.
1 V+35V 37.0 V+35V 12
2 GND 0 GND 11
3NC 0 NC 10
4 GND 0 GND 9
5 V+12V 11.8 V+12V 8
6 GND 0 GND 7
7 V+6_5V 6.7 V+6_5V 6
8 V+5_1V_STB 5.1 V+5_1V_STB 5
9 V+5_1V 5.0 V+5_1V 4
10 V+5_1V 5.0 V+5_1V 3
11 GND 0 GND 2
12 V+3_3V_STB 3.4 V+3_3V_STB 1
CN3752 (KM200NA11)
Voltage
(V)
CN4007 (KM200NA11)
No. Pin Name Pin Name No.
11 PSW_A 2.8 PSW_A 11
10 SDA_AU 3.4 SDA_AU 10
9 SCL_AU 3.4 SCL_AU 9
8 A_MUTE 0 A_MUTE 8
7 A_STBY_B 3.4 A_STBY_B 7
6 GND 0 GND 6
5 AUDIO_R 0 AUDIO_R 5
4 GND 0 GND 4
3 AUDIO_L 0 AUDIO_L 3
2 GND 0 GND 2
1 A_NG_B 2.8 A_NG_B 1
MAIN Assy
AUDIO MAIN Assy
Voltage
(V)
CN4015 (B3P-VH)
No. Pin Name Pin Name No.
17.2 V+16_5V 1
0 GND 2
0 GND 3
DVI JIG MAIN Assy
Voltage
(V)
CN4011 (AKM1274)
No. Pin Name Pin Name No.
0 GND 1
3.4 V+3_3V_STB 2
6.5 V+6_5V 3
LED IR Assy CN9701 (AKP1303)
SIDE KEY Assy
CN9501 (KM200NA4L)
Voltage
(V)
CN4010 (KM200NA7)
No. Pin Name Pin Name No.
2 REM 0 REM 7
6 GND 0 GND 6
1 V+5_1V_STB 5.0 V+5_1V_STB 5
4 V+3_3V_STB 3.4 V+3_3V_STB 4
3 KEY_AD1 3.4 KEY_AD1 3
2 KEY_AD2 3.4 KEY_AD2 2
1 GND 0 GND 1

Pioneer PDP-507XD Specifications

General

Comb filter	3D
Aspect ratio	16:9
Product color	Black
Noise reduction	Yes
Display diagonal	50 \
Display brightness	1100 cd/m²
Display resolution	1365 x 768 pixels
Display technology	Plasma
Viewable size diagonal	1270 mm
Contrast ratio (typical)	4000:1
