PDP-507XD
67
5678
56
7
8
C
D
F
A
B
E
POWER SUPPLY Unit MAIN Assy
P8 (B13B-PH-K-S)
Voltage
(V)
CN4002 (KM200NA13)
No. Pin Name Pin Name No.
1 V+6_5V 6.6 V+6_5V 1
2 GND 0 GND 2
3 V+12V 12.1 V+12V 3
4 GND 0 GND 4
5 +16.5V 17.2 V+16.5V 5
6 GND 0 GND 6
7 +5_1V 4.9 V+5_1V 7
8 +5_1V 4.9 V+5_1V 8
9 +5_1V 4.9 V+5_1V 9
10 +5_1V 4.9 V+5_1V 10
11 GND-D 0 GND 11
12 GND-D 0 GND 12
13 GND-D 0 GND 13
50LED Assy/KEY Assy MAIN Assy
CN9651/CN9701
Voltage
(V)
CN4006 (KM200NA6)
No. Pin Name No.
1 0.2 LED– 1
2 3.4 LED_ON 2
30LED_OFF 3
40LED_REC 4
50LED_MDM 5
3 0.2 LED– 6
Connector
CN9651
CN9651
CN9651
CN9701
CN9701
CN9701
Pin Name
LED–
LED_ON
LED_OFF
LED_REC
LED_MDM
LED–
PC Assy MAIN Assy
POWER SUPPLY Unit MAIN Assy
P9 (B11B-PH-K-S)
Voltage
(V)
CN4008 (KM200NA11)
No. Pin Name Pin Name No.
1 M-SW-DET 3.4 N.C. 1
2 AC-DET 3.4 AC_DET 2
3 N.C. 3.4 RELAY 3
4 GND-D 0 GND 4
5 STB3_3V 3.4 V+3_3V_STB 5
6 GND-D 0 GND 6
7 STBY5_1V 5.0 V+5_1V_STB 7
8 GND-D 0 GND 8
9 +35V 35.0 V+35V 9
10 GND-D 0 GND 10
11 US-SW 0 US_SW 11
Fan MAIN Assy
Voltage
(V)
CN4009 (KM200NA3)
No. Pin Name Pin Name No.
0 FAN_VCC 1
3.4 FAN_NG1 2
0 GND 3
CN9301 (CKS3826)
Voltage
(V)
CN4018 (AKM1234)
No. Pin Name Pin Name No.
1 V+5V_A 5.0 V+5V_A 12
2 WE ROM 0 WE ROM 11
3 D-sub DET 0 D-sub DET 10
4 V+3.3V_UCOM 3.3 V+3.3V_UCOM 9
5 PC_V 0 PC_V 8
6 PC_H 0 PC_H 7
7 V+9V_A 9.0 V+9V_A 6
8 PC_G 2.4 PC_G 5
9 GND 0 GND 4
10 PC_B 2.4 PC_B 3
11 GND 0 GND 2
12 PC_R 2.4 PC_R 1
LED IR Assy/KEY Assy MAIN Assy
CN9701/CN9501
Voltage
(V)
CN4010 (KM200NA7)
No. Pin Name No.
20REM 7
60GND 6
15V+5.1V_STB 5
4 3.4 V+3.3V_STB 4
3 3.4 KEY_AD1 3
2 3.4 KEY_AD2 2
1
Connector
CN9701
CN9701
CN9701
CN9501
CN9501
CN9501
CN9501
0 GND
Pin Name
REM
GND
V+5.1V_STB
V+3.3V_STB
KEY_AD1
KEY_AD2
GND 1
To Next Page
