LANCE
II
SERVICE
MANUAL
TABLE
VII-IV.
TROUBLESHOOTING
CHART
(LANDING
GEAR)
(cont.)
Trouble
Cause
Remedy
Nose
gear
fails
to
Steering
arm
roller
Replace
defective
steer
properly,
sheared
at top
of
roller.
(cont.)
strut.
Steering
bellcrank
Readjust
and
tighten.
loose on
attach-
ment
plate.
Steering
bellcrank
Replace
bearing
and/or
bearing
and/or
bolt.
bolt
worn.
Shimmy
dampener
Replace.
galling
or binding.
Nose
gear
fails
to
Steering
arm
roller
Replace
defective
straighten
when
sheared
at
top
of
roller.
landing
gear
extends.
strut.
Incorrect
rigging
of
Check
nose gear
steer-
nose
gear
steering.
ing adjustment.
Nose
gear
fails
to
Centering
guide
roller
Replace
roller.
straighten
when
sheared.
landing
gear
re-
tracts.
Damaged
guide.
Replace
guide.
