Pitney Bowes 7H20C - Page 13

3. Open the ink carriage guard.
4. Unwrap the printhead and remove the protective strip.
5. Squeeze the tabs and slide the printhead pegs into the lower set of grooves.
Important: This step is critical to prevent device damage.
1 • Installation
Pitney Bowes User Guide March 2023 13
