28
ELECTRONICS
USER INTERFACE PARAMETERS
FIG-1 - RAMP SET-UP MENU
This menu is only available when RAMP has been selected as the FIRE MODE parameter.
FIG-2 - TYPE PARAMETER
Select the type of ramping required:
> STEP:
The marker will re in semi-automatic until a number of trigger pulls (set by SEMI SHOTS)
have been made at a minimum pull rate (set by KICK IN). The marker will then re at up to
the maximum rate of re (set by BS ON ROF) as long as the trigger is continually pulled at a
required rate (set by SUSTAIN).
> LINEAR:
The marker will re in semi-automatic until a number of trigger pulls (set by SEMI SHOTS)
have been made at a minimum pull rate (set by KICK IN). The rate of re will then equal the
rate of trigger pulls increased by a percentage (specied by RATE) up to a maximum rate of
re (set by BS ON ROF). Ramping is maintained as long as the trigger is continually pulled at
a required rate (set by SUSTAIN).
FIG-3 - RATE PARAMETER
Only available when the RAMP TYPE parameter is set to LINEAR. This sets the percentage
increase in rate of re over rate of trigger pulls.
If the RATE is 50% and the trigger is pulled at 10 bps then the actual rate of re is 15 bps
(10 + 50%).
This parameter can be set between 0 and 100% in 10% increments.
