Planet FRT-401 User Manual

66
A.3 Fiber Optical Cable Connection Parameter
The wiring details are as below:
■ Fiber Optical patch Cables:
Standard Fiber Type Cable Specification
100Base-FX
(1300nm)
Multi-mode 50/125μm or 62.5/125μm
Multi-mode 50/125μm or 62.5/125μm 100Base-FX
(1310nm)
Single-mode 9/125μm
100Base-BX-U
(TX :1310/RX :1550)
100Base-BX-D
(TX :1550/RX :1310)
Single-mode 9/125μm
A.4 Available Modules
The following list the available Modules for FRT-40x / 40xN
MFB-FX SFP-Port 100Base-FX Transceiver (1310nm) -2km
MFB-F20 SFP-Port 100Base-FX Transceiver (1310nm) - 20km
MFB-FA20 SFP-Port 100Base-BX Transceiver (WDM,TX:1310nm) -20km
MFB-FB20 SFP-Port 100Base-BX Transceiver (WDM,TX:1550nm) -20km

Planet FRT-401 Specifications

General

Brand	Planet
Model	FRT-401
Category	Wireless Router
Language	English
