68
FRT-401N / FRT-401NS15 / FRT-405N
Product 802.11n Wireless Internet Fiber Router
Model FRT-401N FRT-401NS15 FRT-405N
WAN 1 x 100Base-FX port
LAN 4 x 10/100Base-TX port
Ports
Wireless 1 x 802.11b/g/n Access Point, 2 x antennas detachable
Connector SC SFP
Mode Multi-mode Single-mode Vary on module
Optic
Interface
Distance 2km 15km Vary on module
Optic wavelength 850nm 1310nm -
Max. -14 -7 -
Launch Power(dBm)
Min. -19.0 -20 -
Receive Sensitivity
-34.5 -28 -
Maximum Input power
-14 -8 -
Fiber-optic cable
50/125μm or 62.5/125μm multi-mode fiber cable, up to 2km.
9/125μm single-mode cable, provide long distance for
15/20/35/50km or longer (very on SFP module)
LED Indicators PWR, WPS, WLAN, Security, Fiber, LAN1-4
Button 1 x RESET button, 1 x WPS button
Software
Max. Sessions 4096
Protocol / Feature
Router, Bridge and WISP mode
WDS and WPS
Static Routing and RIPv1/2
DMZ and Virtual Server
802.1D
802.1Q VLAN support
QoS
SNTP
DHCP Server / Client
IGMP Proxy and DNS Proxy
Universal Plug and Play (UPnP) Compliant
DDNS (Dynamic Domain Name System)
Wireless Standard Compliant with IEEE 802.11n, 802.11g and 802.11b standards
Frequency 2.4 to 2.4835GHz (Industrial Scientific Medical Band )
Channels Maximum 14 Channels, depending on regulatory authorities
Antenna 2 x 2dBi detachable Antenna
Wireless Data
Encryption
64 bit / 128 bit WEP, WPA-PSK, WPA, WPA2, 802.1x encryption, and
WPS PBC
Wireless Data Rate
IEEE 802.11b: 1/2/5.5/11Mbps
IEEE 802.11g: 6/9/12/18/24/36/48/54Mbps
IEEE 802.11n: 14/29/43/58/87/116/130/144Mps in 20MHz,
30/60/90/120/180/240/270/300Mbps in 40MHz
Wireless
WDS WDS repeater support
VPN VPN Pass-Through
