Planmeca PlanMill 50 S - Technical Specifications; Milling Unit

17 Technical specifications
Name: Planmeca PlanMill 50 S
Planmeca
Asentajankatu 6,
00880 Helsinki
FINLAND
Tel.: +358 20 7795 500
http://www.planmeca.com
17.1 Milling unit
Type of drive High torque stepper motor
Control Stepper motor controller IME 482
Milling chamber lid Lid hinged to open upwards
Guides Precision steel guides in the X, Y, Z axis
Traverse paths X axis: 150 mm (5.9 in.)
Y axis: 115 mm (4.5 in.)
Z axis: 90 mm (3,5 in.)
A axis: 360 degrees
B axis: 110 degrees
Tool changer 12 tools
Coolant tank 1.8 l
Maximum installation height 2,000 m (6562 ft) above sea level
Dimensions (W x H x D)
566 x 612 x 665 mm
(22,3 x 24,1 x 26,2 in.)
Weight
Approx. 95 kg (209 lbs)
Air supply
Required air pressure: 6 - 9 (continuously applied) bar
Required air volume: 60 l/min (2.1 ft³/min)
Coolant tank
1.8 l (0.48 gal)
High-frequency spindle
Housing Ø33/69 mm (1.3/2.7 in.)
Tool change Pneumatic, direct changer
Collet chuck clamping range 3 mm (0.12 in.)
Acceleration and braking value 10,000 rev/min
17 Technical specifications
User's manual Planmeca PlanMill 50 S 113
