PLUSOPTIX A09 - 13 Specifications

Page 42 of 43
13. Specifications
Measurements
Refraction
binocular and monocular
Spherical range
+5.00/-7.00 dpt in 0.25 dpt steps ± 0.25dpt
Cylindrical range
+5.00/-7.00 dpt in 0.25 dpt steps ± 0.25dpt
Axis
1-180° in 1° steps ± 15°
Pupil size
4.0 – 8.0 mm in 0.1 mm steps ± 10%
Pupil distance
mm in 1.0 mm steps ± 10 %
Time per measurement
0.02 s
Measuring distance
1 m ( ± 5 cm)
Fixation target
Warble sound
Measurement principal
binocular, dynamic photosciascopy
Interfaces and standards
Interfaces
1 x VGA, 4 x USB and 1 x RJ-45
Printers
Linux compatible
Standards
EN 60601-1
Power
Medical Power Adapter
MES30B-3P1J
in 110-240VAC (50 - 60Hz), 0.8A
out 12VDC 2.5A
plusoptiX A09 power
consumption:
12VDC, 1A max.
Environmental requirements
Temperature
operating
10 to 35 °C (50 to 92 °F)
storage
0 to 50 °C (32 to 122 °F)
Humidity
operating
20 - 80 % not condensing
storage
10 - 85 % not condensing
Packaging
Size of carton
51 x 41 x 20 cm (20 x 16 x 8 inches)
Weight
A09 device
2.2 Kg (4.9 LB)
Carton
1.3 Kg (2.6 LB)
Total
3.5 Kg (7.7 LB)
