4.20
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
1. Route the fuel line
q
under the rear seatbase tube
and secure it to the routing T-clip
w
on the engine
mount.
2. Secure the fuel line with a routing clip
e
on the airbox
support.
NOTE
Airbox removed for image clarity.
FUEL SYSTEM
