WALKER EVANS 1.5” REAR SHOCK INFORMATION
ITEM
SPECIFICATION
Shock Travel
7.764
Extended Length 23.264
IFP Depth 3.375
Nitrogen Pressure
200 psi (1379 kPa) +/- 10%
Gas Shock Oil
10 wt WER
Compression Adjustment (factory) 6 clicks CCW from full soft setting
Spring Adjustment Setting
COMPRESSION REBOUND
ADJUSTER
COMPRESSION
ADJUSTER
REBOUND
SHAFT BLEED PISTON BLEED
1.30 x .008 .875 x .090 1.10 x .025 .700 x .010 .082 .067
.900 x .012 .800 x .010 1.10 x .012
1.25 x .008 .900 x .010 1.00 x .025
1.00 x .010 1.00 x 0.10 .625 x .065
.900 x .010 1.10 x .010
.800 x .010 1.25 x .010
.700 x .010
.875 x .090
STEERING / SUSPENSION
