GENERAL INFORMATION
TORQUE SPECIFICATIONS - ELECTRICAL
ELECTRICAL
ITEM
TORQUE
Battery Hold-Down Strap
Fastener
10 ft-lbs (13.5 Nm)
Voltage Regulator
Fasteners
8 ft-lbs (11 Nm)
Starter Mounting
Fasteners
7 ft-lbs (10 Nm)
Ignition Coil Retaining
Bolt
75 in-lb (9 Nm)
ECT Sensor 17 ft-lb (23 Nm)
ECU Fasteners 12 in-lbs (1.3 Nm)
Fuse Block Fasteners
8 ft-lbs (11 Nm)
Starter Connections 60 in-lbs (7 Nm)
Tail Light Fasteners
12 in-lbs (1.3 Nm)
Battery Terminal
Fasteners
6 ft-lbs (8 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PV-43568
Fluke™ 77 Digital Multimeter
PV-43526 Connector Test Kit
2870630
Timing Light
PU-50338
Battery Hydrometer
2460761 Hall Effect Sensor Probe Harness
2871745
Static Timing Light Harness
PU-50296
Battery Conductance Analyzer
(MDX-610P)
PU-49466
Relay Bypass
- Digital Wrench® (see Chapter 4)
Bosch Automotive Service Solutions 1-800-345-2233
or https://polaris.service-solutions.com
