SUSPENSION
WALKER EVANS FRONT / REAR SPRING PRELOAD
The factory setting is appropriate for nearly all riding conditions. If desired, the suspension may be adjusted to maintain
vehicle clearance height when carrying loads.
Front Shock Preload
Measurement
Rear Shock Preload Measurement
FACTORY PRELOAD SETTINGS
LOCATION MEASUREMENT
Front
13.1 in. (33 cm)
Rear
13.75 in. (35 cm)
NOTE
The shock must be removed from the vehicle for accurate measurement.
