SCHEMATIC CABLE/WIRE TERMINATION TABLE
INDEX CCT # TYPE GAUGE COLOR FROM COMPONENT FROM PORT TO COMPONENT TO PORT FUNCTION
1 70 TXL 3.0 YE STATOR AC A REGULATOR AC P3 REGULATOR AC
2 71 TXL 3.0 YE STATOR AC B REGULATOR AC P2 REGULATOR AC
3 72 TXL 3.0 YE STATOR AC C REGULATOR AC P1 REGULATOR AC
4 BAA FUSIBLE LINK 0.8 BU START SOLENOID B+ 1 SPLICE, FUSBILE LINK #1 1 FUSIBLE LINK, UNSWITCHED B+, CHASSIS
5 BAB TXL 2.0 RD SPLICE, UNSWITCHED B+ 1 SPLICE, FUSBILE LINK #1 2 UNSWITCHED B+
6 BAC TXL 2.0 RD SPLICE, UNSWITCHED B+ 2 RELAY/FUSE BLOCK 12 UNSWITCHED B+
7 BAD TXL 2.0 RD RELAY/FUSE BLOCK 4 SPLICE, UNSWITCHED B+ 2 UNSWITCHED B+
8 BAE TXL 2.0 RD RELAY/FUSE BLOCK 28 SPLICE, UNSWITCHED B+ 1 UNSWITCHED B+
9 BAF TXL 2.0 RD RELAY/FUSE BLOCK 20 SPLICE, UNSWITCHED B+ 2 UNSWITCHED B+
10 BBA FUSIBLE LINK 2.0 GY SPLICE, FUSABILE LINK #4 1 START SOLENOID B+ 1 UNSWITCHED, B+
11 BBB TXL 5.0 RD REGULATOR DC P3 SPLICE, FUSABILE LINK #4 2 UNSWITCHED, B+
12 BCA FUSIBLE LINK 0.5 GY START SOLENOID B+ 1 SPLICE, FUSBILE LINK #2 1 FUSIBLE LINK, FAN
13 BCB TXL 1.0 RD/BN RELAY/FUSE BLOCK 36 SPLICE, FUSBILE LINK #2 2 UNSWTICHED B+, FAN CKT BKR
14 BDA FUSIBLE LINK 1.0 BK SPLICE,FUSABILE LINK #3 1 START SOLENOID B+ 1 FUSIBLE LINK, EPS
15 BDB TXL 3.0 RD SPLICE,FUSABILE LINK #3 2 RELAY/FUSE BLOCK 35 UNSWITCHED B+
16 CBA TXL 1.0 RD RELAY/FUSE BLOCK 10 RELAY/FUSE BLOCK 40 UNSWITCHED FUSED,B+ FAN RELAY POWER IN
17 C_A201 TXL 0.5 BK CRANK POSITION SENSOR 2 ECM 2 201 CRANK POSITION SENSOR NEG
18 C_A213 TXL 0.5 WH ECM 2 213 CRANK POSITION SENSOR 1 CRANK POSITION SENSOR POS
19 C_AC SHLD 0.5 SHLD SPLICE, CPS SHIELD 2 SPLICE, SHIELD 1 SHIELD, CPS (C01)
20 C_B254 TXL 0.5 BK ECM 2 254 IGNITION COIL 3 IGNITION CONTROL
21 C_B256 TXL 0.5 WH ECM 2 256 IGNITION COIL 1 IGNITION CONTROL
22 C_BC SHLD 0.5 SHLD TRIM FLUSH - SPLICE, SHIELD 2 SHIELD, IGNITION COIL (C02)
23 C_C103 TXL 0.5 BK PEDAL POSITION SENSOR E ECM 1 103 APS 2 RETURN
24 C_C111 TXL 0.5 WH ECM 1 111 PEDAL POSITION SENSOR F APS SIGNAL 2
25 C_C125 TXL 0.5 RD PEDAL POSITION SENSOR D ECM 1 125 APS 2 5V
26 C_CC SHLD 0.5 SHLD TRIM FLUSH - SPLICE, SHIELD 1 SHIELD, CPS (C01)
27 C_D106 TXL 0.5 BK PEDAL POSITION SENSOR B ECM 1 106 APS 1 RETURN/GND
28 C_D121 TXL 0.5 WH PEDAL POSITION SENSOR A ECM 1 121 APS 1 SIGNAL
29 C_D210 TXL 0.5 RD ECM 2 210 PEDAL POSITION SENSOR C APS 1 5V
30 C_DC SHLD 0.5 SHLD TRIM FLUSH - SPLICE, SHIELD 1 SHIELD, CPS (C01)
31 C_E251 TXL 0.5 RD ELECTRONIC THROTTLE BODY 5 ECM 2 251 ETC MOTOR (+)
32 C_E252 TXL 0.5 BK ECM 2 252 ELECTRONIC THROTTLE BODY 3 ETC MOTOR (-)
33 C_EC SHLD 0.5 SHLD TRIM FLUSH - SPLICE, SHIELD 1 SHIELD, CPS (C01)
34 E104 TXL 0.5 VT ECM 1 104 TMAP 1 MANIFOLD PRESSURE GROUND
35 E105 TXL 0.5 VT ECM 1 105 ELECTRONIC THROTTLE BODY 2 TPS RETURN
36 E115 TXL 0.5 DG/YE ECM 1 115 RELAY/FUSE BLOCK 6 ECM RELAY COIL CONTROL
37 E120 TXL (SBBC) 0.5 GY AWD SWITCH 3 ECM 1 120 AWD REQUEST
38 E123 TXL 0.5 WH ECM 1 123 TRANSMISSION SWITCH B TRANSMISSION SWITCH SIGNAL OUTPUT
39 E132A TXL 0.5TP YE ECM 1 132 SPLICE, CAN HIGH 1 CAN HIGH
40 E132B TXL 0.5TP YE DIAGNOSTIC H SPLICE, CAN HIGH 2 CAN HIGH
41 E132C TXL 0.5TP YE SPEEDOMETER 1 SPLICE, CAN HIGH 2 CAN HIGH
42 E132D TXL 0.5TP YE EPS SIGNAL 8 SPLICE, CAN HIGH 1 CAN HIGH
43 E138 TXL 0.5 OG ECM 1 138 ELECTRONIC THROTTLE BODY 6 TPS 3.3V SUPPLY
44 E140 TXL 0.5 WH ECM 1 140 RELAY/FUSE BLOCK 8 CHASSIS RELAY COIL LOW
45 E141 TXL 0.5 OG/WH ECM 1 141 RELAY/FUSE BLOCK 14 FAN RELAY COIL CONTROL
46 E142 TXL 0.5 DG/YE ECM 1 142 RELAY/FUSE BLOCK 22 FUEL PUMP RELAY COIL CONTROL
47 E144A TXL 0.5TP DG ECM 1 144 SPLICE, CAN LOW 1 CAN LOW
48 E144B TXL 0.5TP DG DIAGNOSTIC G SPLICE, CAN LOW 2 CAN LOW
49 E144C TXL 0.5TP DG SPEEDOMETER 2 SPLICE, CAN LOW 2 CAN LOW
50 E144D TXL 0.5TP DG EPS SIGNAL 4 SPLICE, CAN LOW 1 CAN LOW
51 E203 TXL 0.5 DG ELECTRONIC THROTTLE BODY 1 ECM 2 203 TPS 1 SIGNAL
52 E204A TXL 0.5 VT/WH ECM 2 204 SPLICE, SENSOR GROUND 1 GROUND, SENSOR
53 E204B TXL 0.5 VT/WH TRANSMISSION SWITCH A SPLICE, SENSOR GROUND 2 GROUND, TRANSMISSION SWITCH
54 E204C TXL 0.5 VT/WH COOLANT TEMP SENSOR 1 SPLICE, SENSOR GROUND 1 GROUND,COOLANT TEMP SENSOR
55 E215 TXL 0.5 YE COOLANT TEMP SENSOR 2 ECM 2 215 COOLANT TEMP SIGNAL
56 E219 TXL 0.5 YE ECM 2 219 TMAP 4 MANIFOLD PRESSURE SIGNAL
57 E220 TXL 0.5 BU ECM 2 220 ELECTRONIC THROTTLE BODY 4 TPS 2 SIGNAL
58 E223 TXL 0.5 OG ECM 2 223 TMAP 3 A/D +5V SOURCE
59 E225 TXL 0.5 DB/YE SEAT BELT SWITCH B ECM 2 225 SEAT BELT SWITCH SIGNAL
60 E227 TXL 0.5 DB ECM 2 227 TMAP 2 AIR TEMP SENSOR SIGNAL
61 E232 TXL 0.5 GN/RD VEHICLE SPEED SENSOR C ECM 2 232 VEHICLE SPEED SIGNAL
62 E243 TXL 0.5 WH ECM 2 243 PTO INJECTOR DRIVER 1 INJECTOR DRIVER
63 E244 TXL 0.5 BK ECM 2 244 MAG INJECTOR DRIVER 1 INJECTOR DRIVER
64 E246 TXL 0.5 BN/WH ECM 2 246 AWD B AWD COIL CONTROL
65 FAA TXL 1.0 OG/WH SPLICE,ACCESSORY 2 RELAY/FUSE BLOCK 31 ACCESSORY B+, FUSE OUT
66 FAB TXL 2.0 OG/WH SPLICE,ACCESSORY 1 ACCESSORY, FRONT TB 1 ACCESSORY B+, SPLICE TIE
67 FAC TXL 1.0 OG/WH SPLICE,ACCESSORY 2 ACCESSORY, REAR P1 ACCESSORY B+, REAR
68 FAD TXL 1.0 OG/WH 12V RECEPTACLE B+ 1 ACCESSORY, FRONT TB 1 ACCESSORY B+, POWER POINT
69 FDA TXL 0.5 RD/DG SPLICE, DRIVE 2 RELAY/FUSE BLOCK 23 SWITCHED, B+
70 FDB TXL 0.5 RD/DG AWD C SPLICE, DRIVE 2 SWITCHED, B+
71 FJA TXL 1.0 RD/WH SPLICE, UNSWITCHED FUSED EFI 2 RELAY/FUSE BLOCK 24 UNSWITCHED FUSED EFI B+
72 FJB TXL 1.0 RD/WH RELAY/FUSE BLOCK 2 SPLICE, UNSWITCHED FUSED EFI 1 UNSWITCHED FUSED EFI B+
73 FJG TXL 0.5 RD/WH SPLICE, UNSWITCHED FUSED EFI 1 RELAY/FUSE BLOCK 1 UNSWITCHED FUSED EFI B+
74 FLA TXL 1.0 RD/YE SPLICE, LIGHTS REAR 2 RELAY/FUSE BLOCK 15 LIGHTS
75 FLB TXL 1.0 RD/YE SPLICE, LIGHTS REAR 2 SPLICE, LIGHTS FRONT 2 LIGHTS B+
76 FLC TXL 0.8 RD/YE SPLICE, LIGHTS REAR 1 LH TAILLIGHT A LIGHTS B+, LH TAIL LIGHT
77 FLD TXL 0.8 RD/YE SPLICE, LIGHTS REAR 1 RH TAILLIGHT A LIGHTS B+, RH TAIL LIGHT
78 FLE TXL 0.8 RD/YE BRAKE SWITCH A SPLICE, LIGHTS FRONT 2 LIGHTS, BRAKE SW
79 FLJ TXL 0.8 RD/YE SPLICE, LIGHTS FRONT 1 RH HEADLIGHT B LIGHTS
80 FLK TXL 0.8 RD/YE SPLICE, LIGHTS FRONT 1 LH HEADLIGHT B LIGHTS
81 FP TXL 1.0 RD/GN RELAY/FUSE BLOCK 16 RELAY/FUSE BLOCK 18 FUEL PUMP FUSE RELAY, B+
82 FT TXL 3.0 RD RELAY/FUSE BLOCK 34 RELAY/FUSE BLOCK 39 UNSWITCHED B+
83 FUA TXL 0.5 RD/BK RELAY/FUSE BLOCK 32 SPLICE, UNSWITCHED FUSED B+ 2 UNSWITCHED FUSED B+
84 FUB TXL 0.5 RD/BK SPLICE, UNSWITCHED FUSED B+ 1 DIAGNOSTIC A UNSWITCHED FUSED B+
85 FUD TXL 0.5 RD/BK SPLICE, UNSWITCHED FUSED B+ 2 KEY SWITCH C UNSWITCHED FUSED B+
86 FUE TXL 0.5 RD/BK SPEEDOMETER 4 KEY SWITCH C UNSWITCHED FUSED B+
87 GA153 TXL 0.5 BN ECM 1 153 GROUND A 1 GROUND
88 GA154 TXL 0.5 BN ECM 1 154 GROUND A 1 GROUND
89 GA247 TXL 0.5 BN ECM 2 247 GROUND A 1 GROUND
90 GA250 TXL 0.5 BN ECM 2 250 GROUND A 1 GROUND
91 GADA TXL 0.8 BN GROUND A 1 SPLICE, SHIELD 1 GROUND
92 GADB TXL 0.5 BN CRANK POSITION SENSOR 3 SPLICE, CPS SHIELD 1 CPS SHIELD
93 GADC TXL 0.5 BN GROUND,IGN. COIL P1 SPLICE, SHIELD 2 SHIELD, IGNITION COIL (C02)
94 GAF TXL 0.5 BN RELAY/FUSE BLOCK 38 GROUND A 1 GROUND
95 GBA TXL 0.5 BN VEHICLE SPEED SENSOR B GROUND B 1 GROUND
96 GBAA TXL 5.0 BN GROUND B, FRONT TB 1 SPLICE, GROUND FRONT 2 GROUND
97 GBAB TXL 1.0 BN 12V RECEPTACLE GROUND 1 SPLICE, GROUND FRONT 2 GROUND, 12V RECEPTACLE
98 GBAC TXL 0.5 BN AWD SWITCH 2 SPLICE, GROUND FRONT 2 GROUND, AWD SWITCH
99 GBAF TXL 0.5 BN DIAGNOSTIC D SPLICE, GROUND FRONT 1 GROUND, DIAGNOSTIC
100 GBAH TXL 1.0 BN SPLICE, GROUND FRONT 2 KEY SWITCH A GROUND
101 GBB TXL 1.0 BN FAN A GROUND B, FRONT TB 1 GROUND, FAN
102 GBC TXL 3.0 BN EPS POWER B GROUND B, FRONT TB 1 GROUND
02/03/17
SCHEMATIC CABLE/WIRE TERMINATION TABLE
INDEX CCT # TYPE GAUGE COLOR FROM COMPONENT FROM PORT TO COMPONENT TO PORT FUNCTION
103 GBCA TXL 3.0 BN SPLICE, GROUND REAR 1 GROUND B 1 GROUND
104 GBCD TXL 0.5 BN SPEEDOMETER 5 SPLICE, GROUND REAR 2 GROUND, SPEEDOMETER
105 GBCE TXL 0.5 BN FUEL PUMP/LEVEL 2 SPLICE, GROUND REAR 2 GROUND
106 GBCG TXL 1.0 BN ACCESSORY, REAR P2 SPLICE, GROUND REAR 2 GROUND
107 GBCH TXL 0.8 BN SPLICE, GROUND REAR 2 RH TAILLIGHT C GROUND
108 GBCJ TXL 0.8 BN SPLICE, GROUND REAR 2 LH TAILLIGHT C GROUND
109 GBD TXL 5.0 BN GROUND B 1 REGULATOR DC P1 GROUND
110 GBE TXL 1.0 BN FUEL PUMP/LEVEL 4 GROUND B 1 GROUND
111 KB TXL 0.8 DG/WH START SOLENOID 1 KEY SWITCH B START SOLENOID CONTROL GROUND
112 KD116 TXL 0.5 OG ECM 1 116 SPLICE, R/S B+ 2 KEY SWITCH, B+
113 KDA TXL 0.8 OG KEY SWITCH D SPLICE, R/S B+ 2 KEY SWITCH, B+
114 KDB TXL 0.5 OG SPEEDOMETER 3 SPLICE, R/S B+ 1 KEY SWITCH, B+
115 KDD TXL 0.8 OG SPLICE, R/S B+ 2 RELAY/FUSE BLOCK 3 KEY SWITCH, B+
116 KDF TXL 0.5 OG DIAGNOSTIC B SPLICE, R/S B+ 1 KEY SWITCH, B+
117 KDG TXL 0.5 OG VEHICLE SPEED SENSOR A SPLICE, R/S B+ 2 KEY SWITCH, B+
118 KDH TXL 0.5 OG RELAY/FUSE BLOCK 33 SPLICE, R/S B+ 2 KEY SWITCH, B+
119 KDJ TXL 0.5 OG EPS SIGNAL 3 SPLICE, R/S B+ 2 KEY SWITCH, B+
120 KDK TXL 0.5 OG SPLICE, R/S B+ 2 AWD SWITCH 7 KEY SWITCH, B+
121 RCA TXL 2.0 WH RELAY/FUSE BLOCK 7 SPLICE, CHASSIS B+ 1 SWITCHED B+
122 RCB TXL 1.0 WH RELAY/FUSE BLOCK 11 SPLICE, CHASSIS B+ 1 SWITCHED B+
123 RCC TXL 1.0 WH RELAY/FUSE BLOCK 27 SPLICE, CHASSIS B+ 1 SWITCHED B+
124 RCD TXL 1.0 WH RELAY/FUSE BLOCK 19 SPLICE, CHASSIS B+ 2 SWITCHED B+
125 RF TXL 1.0 OG/BK RELAY/FUSE BLOCK 13 FAN B FAN, B+ FAN RELAY OUT
126 RJ155 TXL 0.5 RD/DB ECM 1 155 SPLICE, IGNITION 1 EFI RELAY B+
127 RJ156 TXL 0.5 RD/DB ECM 1 156 SPLICE, IGNITION 1 EFI RELAY B+
128 RJA TXL 1.0 RD/DB RELAY/FUSE BLOCK 5 SPLICE, IGNITION 1 EFI RELAY B+
129 RJB TXL 0.5 RD/DB RELAY/FUSE BLOCK 9 SPLICE, IGNITION 1 EFI RELAY B+
130 RJC TXL 0.5 RD/DB MAG INJECTOR DRIVER 2 SPLICE, IGNITION 2 EFI RELAY B+
131 RJD TXL 0.5 RD/DB RELAY/FUSE BLOCK 17 SPLICE, IGNITION 2 EFI RELAY B+
132 RJE TXL 0.5 RD/DB SEAT BELT SWITCH A SPLICE, IGNITION 2 EFI RELAY B+
133 RJF TXL 0.5 RD/DB PTO INJECTOR DRIVER 2 SPLICE, IGNITION 2 EFI RELAY B+
134 RJG TXL 0.5 RD/DB IGNITION COIL 2 SPLICE, IGNITION 2 EFI RELAY B+
135 RP TXL 1.0 RD/BU RELAY/FUSE BLOCK 21 FUEL PUMP/LEVEL 3 FUEL PUMP RELAY OUT
136 RT TXL 3.0 OG RELAY/FUSE BLOCK 37 EPS POWER A SWITCHED B+
137 S11 TXL 0.5 VT/WH FUEL PUMP/LEVEL 1 SPEEDOMETER 11 FUEL SENSOR
138 XBA TXL 0.8 OG BRAKE SWITCH B SPLICE, BRAKE 2 BRAKE SIGNAL
139 XBB TXL 0.8 OG RELAY/FUSE BLOCK 25 SPLICE, BRAKE 2 BRAKE SIGNAL
140 XBC_135 TXL 0.8 OG ECM 1 135 SPLICE, BRAKE 1 BRAKE SIGNAL
141 XBD TXL 0.8 OG START SOLENOID 2 SPLICE, BRAKE 1 BRAKE SIGNAL
142 XBE TXL 0.8 OG RELAY/FUSE BLOCK 29 SPLICE, BRAKE 2 BRAKE SIGNAL
143 XBF TXL 0.8 OG RH TAILLIGHT B SPLICE, BRAKE 1 BRAKE SIGNAL
144 XBG TXL 0.8 OG SPLICE, BRAKE 1 LH TAILLIGHT B BRAKE SIGNAL
145 XLA TXL 0.8 DG KEY SWITCH F RH HEADLIGHT A RH HEADLIGHT LOW BEAM
146 XLC TXL 0.8 DG LH HEADLIGHT A KEY SWITCH F LH HEADLIGHT LOW BEAM
02/03/17
WIRE PREFIX LEGEND
WIRE PREFIX FUNCTION
B BATTERY VOLTAGE WHEN BATTERY IS CONNECTED
K BATTERY VOLTAGE WHEN KEY AND RUN/STOP SWITCHES ARE ON
G GROUND
F FUSE OUTPUT
FA ACCESSORIES
FC CHASSIS
FD DRIVE
FE ECM
FJ FUEL INJECTION
FL LIGHTS (LOW BEAM IF SEPARATE)
FM LIGHTS, HIGH BEAM
FP FUEL PUMP
FS STARTER
FT POWER STEERING
FU UNSWITCHED
FZ HAZARD
R RELAY OUTPUT
RA ACCESSORIES
RB BATTERY
RC CHASSIS
RE ECM
RF FAN
RJ FUEL INJECTION
RL LIGHTS, LOW BEAM
RM LIGHTS, HIGH BEAM
RP FUEL PUMP
RS STARTER
RT POWER STEERING
X SWITCH OUTPUT
XB BRAKE
XC ADC or ADC/AWD 2
XD AWD or ADC/AWD 1
XH HIGH BEAM
XL LOW BEAM
XT TURF
XWH HANDWARMER HIGH
XWL HANDWARMER LOW
XWT THUMBWARMER
XN HORN
XS START COMMAND
XTL TURN SIGNAL LEFT
XTR TURN SIGNAL RIGHT
XR REVERSE COMMAND
XV REVERSE OVERRIDE COMMAND
XZ HAZARD
E ECM PIN NUMBER
S SPEEDOMETER PIN NUMBER
CB CIRCUIT BREAKER OUTPUT
H HAZARD/TURN FLASHER PIN NUMBER
A ABS ECU
BUS INTERNAL BUSS IN THE LOAD CENTER
NUMBER MISCELLANEOUS
12
3
45
A
B
C
D
E
WIRE COLOR LEGEND
BG
BK
BU
DB
BN
GY
GN
DG
OG
PK
RD
VT
WH
YE
BEIGE (TAN)
BLACK
LIGHT BLUE
DARK BLUE
BROWN
GRAY
LIGHT GREEN
DARK GREEN
ORANGE
PINK
RED
VIOLET (PURPLE)
WHITE
YELLOW
TWO WIRE COLORS ARE SHOWN
WITH MAIN/TRACE COLORS.
EXAMPLE:RD/YE = RED WITH
YELLOW TRACE.
MY18-19 ACE 900 XC ETC
Schematic
FILE NAME: 2413941.RSD
E = ENGINE GROUND
C = CHASSIS GROUND
NC = SWITCH NORMALLY CLOSED
NO = SWITCH NORMALLY OPEN
HARNESS: 2413941-01
SHEET NO. 2 OF 2
DRAWN BY: B.BRANDT 2-FEB-17
CL CLEAR
To Previous Page
Loading...
Need help?
General
