9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
3.21
STATOR COVER TORQUE SEQUENCE
NOTE
When reinstalling stator cover, do not force stator cover to fit. Align the oil pump shaft with the balance shaft drive
tang. Turn the engine by rotating the drive clutch or similar method to turn balance shaft.
ENGINE / COOLING SYSTEM
