Polaris RANGER ETX 2016 - Seat Mounting; Seat Belts

10.10
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
SEAT MOUNTING / SEAT BELTS
REF.
DESCRIPTION NOTES
q
Seat Back
w
Seat Base
e
LH Seat Belt Assm
r
RH Seat Belt Assm
t
Seat Base Frame
y
Screw 24 in-lbs (3 Nm)
u
Bolt
40 ft-lbs (54 Nm)
BODY / FRAME
