1.12
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
MODEL: 2016 RANGER 570 4X4
MODEL NUMBER:
R16RMA57A1, A4, A9, F1, N1, F1E, F1T
R16RME57AS, A9, FH, FHE, FHT
R16RMS57F1
CATEGORY
DIMENSION /
CAPACITY
Length
110″ / 279.4 cm
Width 58″ / 147.3 cm
Height
73″ / 185 cm
Wheel Base 73″ / 185 cm
Ground Clearance 10″ / 25.4 cm
Turning Radius
150″ / 381 cm
Dry Weight
1074 lbs. / 487 kg
1101 lbs. / 499 kg (W /
EPS)
Cargo Box Capacity 500 lbs. / 227 kg
Cargo Box Dimensions
(inside dimensions)
L- 42″ x W-32″ x H-11.5″
(107 x 81 x 29 cm)
Vehicle Payload
1000 lbs. / 454 kg
(Includes weight of
riders, cargo and
accessories)
Towing Capacity 1500 lbs. / 680.4kg
Hitch Tongue Capacity 150 lbs. / 68 kg
GENERAL INFORMATION
