8.2
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
TORQUE SPECIFICATIONS
ITEM
TORQUE VALUE
Body T-40 Screws 8 ft-lbs (11 Nm)
Bearing Carrier Fasteners 40 ft-lbs (54 Nm)
Ball Joint Fastener
30 ft-lbs (41 Nm)
Control Arm Fasteners 40 ft-lbs (54 Nm)
Hub Castle Nut (front) 90 ft-lbs (122 Nm)
Hub Castle Nut (rear) 110 ft-lbs (150 Nm)
Seat Belt Mounting
Fasteners
40 ft-lbs (54 Nm)
Shock Mounting Bolts
(rear)
40 ft-lbs (54 Nm)
Steering Rack Mounting
Bolts
16 ft-lbs (22 Nm)
Steering Shaft to EPS 20 ft-lbs (27 Nm)
Steering Shaft to Steering
Rack
46–51 ft-lbs (62-69 Nm)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Strut Casting Pinch Bolt 26 ft-lbs (35 Nm)
Strut Rod Retaining Nut
(Top)
15 ft-lbs (21 Nm)
Tie Rod End Jamb Nut
14 ft-lbs (19 Nm)
Tie Rod End Mounting
Nut
40 ft-lbs (54 Nm)
Wheel Lug Nuts (Steel
Wheels)
36 ft-lbs (49 Nm)
Wheel Lug Nuts
(Aluminum Wheels)
30 ft-lbs + 90º (41 Nm +
90º)
NOTE
Refer to exploded views throughout this chapter for
more torque specifications, component identification,
and location of components.
STEERING / SUSPENSION
