5.2
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
GENERAL INFORMATION
SPECIAL TOOLS
PART
NUM-
BER
TOOL DESCRIPTION
PU-
50658-A
Clutch Center to Center Distance Tool
PA-48595 Clutch Puller
9314177
Clutch Holding Wrench
2871358-
A
Clutch Holding Fixture
2870341
Drive Clutch Spider Removal and Install
Tool
2870913 Driven Clutch Puller
2870910 Roller Pin Tool
2871226
Clutch Bushing
Replacement Tool Kit
2870386 Piston Pin Puller
PU-
50518
Universal Clutch Compressor Tool
2871025
Clutch Bushing
Replacement Tool Kit
2870654
Standard Clutch Alignment Tool
PART
NUM-
BER
SPECIAL SUPPLIES
N/A
Loctite™ 680
8560054
RTV Silicone Sealer
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
PVT SYSTEM FASTENER TORQUES
ITEM
TORQUE VALUE
Drive Clutch Retaining
Bolt
45 ft-lbs (61 Nm)
Drive Clutch Spider 290 ft-lbs (393 Nm)
Drive Clutch Cover Plate
8 ft-lbs (10 Nm)
Driven Clutch Retaining
Bolt
38 ft-lbs (51 Nm)
PVT Inner Cover Phillips-
Head Screws
50 in-lbs (5 Nm)
PVT Inner Cover Hex-
Head Screws
12 ft-lbs (16 Nm)
PVT Outer Cover Bolts
50 in-lbs (5 Nm)
PVT SYSTEM
