9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
5.15
5. Fully insert the NEW engine to transmission coupler
bolts
e
. Install NEW washers
t
and torque NEW
nuts
y
to specification.
TORQUE
Engine to Transmission Coupler Nuts:
88 ft-lbs (119 Nm)
6. Reinstall PVT Inner Cover, Driven Clutch, Drive
Clutch and PVT Outer Cover.
PVT SYSTEM
