9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
8.15
9. Apply Loctite™ 242 (PN 2871949) to threads of
retaining plate screws or install new screws with pre-
applied locking agent. Torque screws to
specification.
TORQUE
Ball Joint Retaining Plate Screws:
8 ft-lbs (11 Nm)
10. Install A-arm on ball joint and torque castle nut to
specification.
TORQUE
Ball Joint Nut:
30 ft-lbs (41 Nm)
11. Install new cotter pin with open ends toward rear of
machine.
STEERING / SUSPENSION
