3. 3. Technical specifi cations of the
power source PS 164-2
3. 3. 1. Design features
The power source groups together the current source,
the electronic control and the cooling for the torch.
All connections are plugged on the connection panel
co in front of the power source.
On the front face, there are a key board and a dis-
play for the programmation and the follow-up of the
welding cycle, the card reader and the printer.
Fig. 3.8 - Description of power source PS 164-2
1 Screen 4 Memo card drive
2 Synoptic 5 Printer
3 Key board 6 Connection panel
