6. 5. 1. Trouble shooting
6. 5. 1. 1. Noted defect when operating
Observed defect Possible causes What to do
The power source cannot
be turned on
• F2 or F3 fuse defect
• Mains connection cable or plug defect
• Remote control pendant BP 1436 defect
(emergency stop clamped)
• K1 relay defect or disconnected from its
place
• On/off switch defect
• Wrong mains voltage selections
• + 5 V power card defect
• Synoptic card 21700634 defect
• Change (chap. 6.2.1)
• Change
• Check and correct or change
• Check and correct or change
• Check and replace
• Correct and check fuses
• Replace
• Replace
The circuit breaker (out-
side the power source) re-
leases when switching on
• Unsuitable circuit breaker • Use a 20 A circuit breaker
with D graph
The welding cycle or an
axis (rotation, wire, gas or
cooling) is self starting
• Power source is not grounded
• Remote control pendant defect
• Screening of remote pendant cable deterio-
red
• Synoptic card 21700634 defect
• Correct
• Check and repair or change
• Change the cable
• Replace
Some push buttons of the
remote pendant are ino-
perative
• Remote control pendant defect
• Synoptic card 21700634 defect
• Check and repair or change
• Replace
The screened programme
number is not similar to
the selected one on the
remote pendant
• Remote control pendant defect
• Synoptic card 21700634 defect
• Check and repair or change
• Replace
Some programmes are
deleted from the power
source memory
• Wrong operating (deleting of the program-
mes with SY 24 button)
• The 21700633 card has been changed
• RAM memory of 21700633 card defect
• Reintroduce the programmes
• Load again the programmes
• Replace the memory
Value of some parameters
of the card is changed
• Memory card defect • Record a new memory card
Value of parameters can-
not be changed ("+" and
"-" push buttons are ino-
perative )
• SY26 switch key is in position "Modifi cation
non authorised"
• Change the position
Some push buttons of the
programming panel are
inoperative
• Programming synoptic defect
• Synoptic card 21700634 defect
• Call After Sales Service
• Replace
No display • +5 V power defect
• Ram memory of 21700633 card defect
• FU1 and FU2 defect
• Check its fuse and change
• Replace the memory of the
card.
It is impossible to start
a weld cycle (the indica-
tor of the control panel is
fl ashing)
• There is no program with the number you
have chosen on the power source
• Check the program number
(§ 5.4.2)
