POLYtij S1i - 3.3 Technical Specifications

12
3.3 Technical Specifications
A. Performance Index
Items
Specifications
Note
Technical source
HP TIJ 2.5 Thermal Ink Jet technology
Dimension
Controller(H*W*D): 151*93*32mm
Printer head(H*W*D): 175*52*33mm
Bracket size
3pcs steel tubes with diameter at 16mm
1pcs with length 350mm, 2pcs with length 280mm
Clamp and bracket
not included
Power
30V/1A, 30W
With power adapter
Print height
1-12.7mm
Printing speed
and resolution
Horizontal resolution
(DPI)
Maximum speed (m/min)
600
30.4
400
45.7
300
60.9
150
121.9
Print application
Barcode, alphabetic, numeric, image logos,
date/time, expiration date, shift code, counter, lot-box
code
Connection Ports
1.Ethernet port;
2.USB2.0 port;
3.DB15 port.
4.DB25 port.
Interface
5inch full-color large LCD touch screen with
resolution 800*480.
Ink management
1.Automatically recognize ink types, and identify
optimum printing parameters for each ink type;
2. Guarantees genuine original HP ink using;
3. Automatic measure system for the usage condition
of ink.
Installation method
Side printing, down printing and anti-shock bracket.
Product Certification
CE, FCC.
Working
Environment
1. Working environment: -10°C~ +55°C; 10%-85%RH;
2. Storage environment: -25°C~ +80°C; 10%-90%RH.
B. Features:
Items
Specifications
Note
Language
Chinese, English, Japanese, French, German,
Spanish, Portuguese and Russian.
Font
Default font is Arial; allow users to load fonts they
need.
Barcode
UPCA, UPCE, EAN13, EAN8, INT25, CODE39,
CODE128, EAN128, PDF417, DATAMATRIX, QR.
Date format
Variety of date format available
Counter
Flexible setting for common counter, carton counters.
pallet number
Print speed
Print speed can be set up, automatically testing, or
speed testing by external encoder.
Built-in photocell
Suitable for simple print
C. Ink Solutions:
1. Support 42ml, 370ml, 350ml cartridges of HP TIJ2.5technology;
2. Support ink of various colors: black, red, green, yellow and blue;
3. Support porous, semi-porous and non-porous substrates.
