POLYtij S1i - Add Image; Add Counter

19
5.3.5 Add Image
Click to add image
Select a image on file list by page
up and down ( Image 13).
file list
(Image 13)
Note: When there is no image file found,
a window jump out to remind you image
importing (Image 14).
See 5.5.1 ImageManagement for
image logo import.
(Image 14)
5.3.6 Add Counter
Click to add counter.
Click
for options of common
counter, box number, lot number.
A. Click
for common countersetting:
minimum value, maximum value, stepping
value, repeat number ( Image 15).
Common
counter
Box No.
Lot No.
Stepping
value
Repeat
number
(Image 15)
B. Click
to enter box number and
pallet number interface, current value, mini
value, max value, step value for cartonand
pallet number (see Image 16).
Note:
1. Please set up carton number at
first ,then set up pallet number
2. No duplicate value setting options for
carton and pallet number.
Minimum
value
Maximum
value
(Image 16)
value
