31
Click on line speedsetting
interface to run speed test
( Image 35, 36).
Line speed test: input test object length
0~3000mm, click
to enter speedtest
startup interface, then start production line,
put test object onto production line, the
photocell will be sensing the object, and the
machine will calculate line speed
automatically. Click to save current
speed test result. Click , current
speed test value will not be saved. If test
repeated, system will take average value of
multiple results. Click to stop speed
test, and click or to save or
give up test result.
Speed
Test object
length
Run speed test
Cancel
Save
(Image 35)
Stop speed
test
(Image 36)
Note: if external encoder is connected, system would detect encoder automatically, and
change line speed interface to encoder DPI setting interface. User will not be able to set
the line speed
5.4.4 User Management
Click on system management interface to enter user management
A. Device name: user-defined available, the
maximum is 15 characters.
B. User permission management switch:
system
default OFF. A dialogue box requests user
name and password for access to log in.
C. User name : Create user name according
to different permissions, managers as the
highest authority, can set up and modify the
password; engineers can edit the data and turn
off printing; the operator only open and close
the print data available.
D. Password and confirmation:
administrator creates user name and
password. Maximum 15 characters for
password.
888888 is default password for administrator
