Configuration Prog. no. Level Standard value
Contact type H1
NC | NO
5951 C NO
Voltage value 1 H1 5953 E 0
Function value 1 H1 5954 E 0
Voltage value 2 H1 5955 E 10
Function value 2 H1 5956 E 100
Function input H4
None | Optg mode change CHs+HW | Optg mode changeover HW | Optg mode
changeover CHs | Optg mode changeover CH1 | Optg mode changeover CH2 |
Optg mode changeover CH3 | Heat generation lock | Error/alarm message |
Consumer request VK1 | Consumer request VK2 | Release swimpool source
htg | Excess heat discharge | Release swi pool solar | Operating level HW |
Operating level CH1 | Operating level CH2 | Operating level CH3 | Room
thermostat CH1 | Room thermostat CH2 | Room thermostat CH3 | Hot water
thermostat | Pulse count | Checkb sign flue gas damper | Start prevention | Flow
measurement Hz
5970 C None
Contact type H4
NC | NO
5971 C NO
Frequency value 1 H4 5973 E 0
Function value 1 H4 5974 E 0
Frequency value 2 H4 5975 E 0
Function value 2 H4 5976 E 0
Function input H5
None | Optg mode change CHs+HW | Optg mode changeover HW | Optg mode
changeover CHs | Optg mode changeover CH1 | Optg mode changeover CH2 |
Optg mode changeover CH3 | Heat generation lock | Error/alarm message |
Consumer request VK1 | Consumer request VK2 | Release swimpool source
htg | Excess heat discharge | Release swi pool solar | Operating level HW |
Operating level CH1 | Operating level CH2 | Operating level CH3 | Room
thermostat CH1 | Room thermostat CH2 | Room thermostat CH3 | Hot water
thermostat | Pulse count | Checkb sign flue gas damper
5977 C None
Contact type H5
NC | NO
5978 C NO
Function output P1
None | Boiler pump Q1 | Hot water pump Q3 | HW interm circ pump Q33 |
heating pump CH1 Q2 | heating pump CH2 Q6 | heating pump CH3 Q20 |
Collector pump Q5 | Solar pump ext exch K9 | Solar pump buffer K8 | Solar
pump swi pool K18
6085 E heating pump CH1
Q2Boiler pump Q1
Sensor type collector
NTC | Pt 1000
6097 E NTC
Readjustm collector sensor 6098 E 0 °C
Readjustm outside sensor 6100 E 0.0 °C
Time constant building 6110 C 10 h
Central setp compensation 6117 E 10 °C
System frost protection
Off | On
6120 E On
Save sensors
No | Yes
6200 C No
Reset to default parameters 6205 C No
Check no. heat source 1 6212 E
Check no. heat source 2 6213 E
Check no. storage tank 6215 E
Check no. heating circuits 6217 E
Software version 6220 E
9 Settings
68 Paramount four 30 – 115 kW 7658013 - 02 - 15092016
